ARM Cortex-A76 Core User Manual

D1.1 AArch32 debug register summary
The following table summarizes the 32-bit and 64-bit debug control registers that are accessible in the
AArch32 Execution state from the internal CP14 interface. These registers are accessed by the MCR and
MRC instructions in the order of CRn, op2, CRm, Op1 or MCRR and MRRC instructions in the order of CRm,
Op1.
For those registers not described in this chapter, see the Arm
®
Architecture Reference Manual Arm
®
v8, for
Arm
®
v8-A architecture profile.
Table D1-1 AArch32 debug register summary
CRn Op2 CRm Op1 Name Type Reset Description
c0 0 c1 0 DBGDSCRint RO
000x0000
Debug Status and Control Register, Internal View
c0 0 c5 0 DBGDTRTXint WO - Debug Data Transfer Register, Transmit, Internal View
c0 0 c5 0 DBGDTRRXint RO
0x00000000
Debug Data Transfer Register, Receive, Internal View
D1 AArch32 debug registers
D1.1 AArch32 debug register summary
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
D1-404
Non-Confidential

ARM Cortex-A76 Core Specifications

General

Architecture	ARMv8.2-A
Microarchitecture	Cortex-A76
Pipeline Depth	13 stages
Frequency	Up to 3.0 GHz
Process Technology	7nm
Core Type	Out-of-order
NEON	Yes
Power Efficiency	Improved over Cortex-A75
Performance Improvement	35% over Cortex-A75
Core Count	1-4 cores per cluster
ISA Support	AArch64 and AArch32
Branch Prediction	Yes
L1 Data Cache	32KB, per core
L2 Cache	256KB or 512KB, per core
L3 Cache	Up to 4MB
Memory Support	LPDDR4, LPDDR4X, DDR4
DynamIQ Shared Unit (DSU)	DynamIQ Shared Unit (DSU)
Cryptography Extensions	Yes
Virtualization Support	Yes
L1 Cache	64 KB per core
