ARM Cortex-A76 Core User Manual

Table B2-1 Registers with implementation defined bit fields (continued)
Name Op0 CRn Op1 CRm Op2 Width Description
CLIDR_EL1 3 c0 1 c0 1 64 B2.19 CLIDR_EL1, Cache Level ID Register, EL1
on page B2-161
CPACR_EL1 3 c1 0 c0 2 32 B2.20 CPACR_EL1, Architectural Feature Access Control
Register, EL1 on page B2-163
CPTR_EL2 3 c1 4 c1 2 32 B2.21 CPTR_EL2, Architectural Feature Trap Register, EL2
on page B2-164
CPTR_EL3 3 c1 6 c1 2 32 B2.22 CPTR_EL3, Architectural Feature Trap Register, EL3
on page B2-165
CSSELR_EL1 3 c0 2 c0 0 32 B2.32 CSSELR_EL1, Cache Size Selection Register, EL1
on page B2-190
CTR_EL0 3 c0 3 c0 1 32 B2.33 CTR_EL0, Cache Type Register, EL0 on page B2-191
DISR_EL1 3 c12 0 c1 1 64 B2.35 DISR_EL1, Deferred Interrupt Status Register, EL1
on page B2-194
ERRIDR_EL1 3 c5 0 c3 0 32 B2.36 ERRIDR_EL1, Error ID Register, EL1 on page B2-196
ERRSELR_EL1 3 c5 0 c3 1 32 B2.37 ERRSELR_EL1, Error Record Select Register, EL1
on page B2-197
ERXADDR_EL1 3 c5 0 c4 3 64 B2.38 ERXADDR_EL1, Selected Error Record Address Register,
EL1 on page B2-198
ERXCTLR_EL1 3 c5 0 c4 1 64 B2.39 ERXCTLR_EL1, Selected Error Record Control Register,
EL1 on page B2-199
ERXFR_EL1 3 c5 0 c4 0 64 B2.40 ERXFR_EL1, Selected Error Record Feature Register, EL1
on page B2-200
ERXMISC0_EL1 3 c5 0 c5 0 64 B2.41 ERXMISC0_EL1, Selected Error Record Miscellaneous
Register 0, EL1 on page B2-201
ERXMISC1_EL1 3 c5 0 c5 1 64 B2.42 ERXMISC1_EL1, Selected Error Record Miscellaneous
Register 1, EL1 on page B2-202
ERXSTATUS_EL1 3 c5 0 c4 2 32 B2.46 ERXSTATUS_EL1, Selected Error Record Primary Status
Register, EL1 on page B2-207
ESR_EL1 3 c5 0 c2 0 32 B2.47 ESR_EL1, Exception Syndrome Register, EL1
on page B2-208
ESR_EL2 3 c5 4 c2 0 32 B2.48 ESR_EL2, Exception Syndrome Register, EL2
on page B2-209
ESR_EL3 3 c5 6 c2 0 32 B2.49 ESR_EL3, Exception Syndrome Register, EL3
on page B2-210
HACR_EL2 3 c1 4 c1 7 32 B2.50 HACR_EL2, Hyp Auxiliary Configuration Register, EL2
on page B2-211
HCR_EL2 3 c1 4 c1 0 64 B2.51 HCR_EL2, Hypervisor Configuration Register, EL2
on page B2-212
ID_AFR0_EL1 3 c0 0 c1 3 32 B2.63 ID_AFR0_EL1, AArch32 Auxiliary Feature Register 0,
EL1 on page B2-230
B2 AArch64 system registers
B2.2 AArch64 architectural system register summary
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
B2-128
Non-Confidential

ARM Cortex-A76 Core Specifications

General

Architecture	ARMv8.2-A
Microarchitecture	Cortex-A76
Pipeline Depth	13 stages
Frequency	Up to 3.0 GHz
Process Technology	7nm
Core Type	Out-of-order
NEON	Yes
Power Efficiency	Improved over Cortex-A75
Performance Improvement	35% over Cortex-A75
Core Count	1-4 cores per cluster
ISA Support	AArch64 and AArch32
Branch Prediction	Yes
L1 Data Cache	32KB, per core
L2 Cache	256KB or 512KB, per core
L3 Cache	Up to 4MB
Memory Support	LPDDR4, LPDDR4X, DDR4
DynamIQ Shared Unit (DSU)	DynamIQ Shared Unit (DSU)
Cryptography Extensions	Yes
Virtualization Support	Yes
L1 Cache	64 KB per core
