ARM Cortex-A76 Core User Manual

Table B2-1 Registers with implementation defined bit fields (continued)
Name Op0 CRn Op1 CRm Op2 Width Description
ID_DFR0_EL1 3 c0 0 c1 2 32 B2.64 ID_DFR0_EL1, AArch32 Debug Feature Register 0, EL1
on page B2-231
ID_ISAR0_EL1 3 c0 0 c2 0 32 B2.65 ID_ISAR0_EL1, AArch32 Instruction Set Attribute
Register 0, EL1 on page B2-233
ID_ISAR1_EL1 3 c0 0 c2 1 32 B2.66 ID_ISAR1_EL1, AArch32 Instruction Set Attribute
Register 1, EL1 on page B2-235
ID_ISAR2_EL1 3 c0 0 c2 2 32 B2.67 ID_ISAR2_EL1, AArch32 Instruction Set Attribute
Register 2, EL1 on page B2-237
ID_ISAR3_EL1 3 c0 0 c2 3 32 B2.68 ID_ISAR3_EL1, AArch32 Instruction Set Attribute
Register 3, EL1 on page B2-239
ID_ISAR4_EL1 3 c0 0 c2 4 32 B2.69 ID_ISAR4_EL1, AArch32 Instruction Set Attribute
Register 4, EL1 on page B2-241
ID_ISAR5_EL1 3 c0 0 c2 5 32 B2.70 ID_ISAR5_EL1, AArch32 Instruction Set Attribute
Register 5, EL1 on page B2-243
ID_ISAR6_EL1 3 c0 0 c2 7 32 B2.71 ID_ISAR6_EL1, AArch32 Instruction Set Attribute
Register 6, EL1 on page B2-245
ID_MMFR0_EL1 3 c0 0 c1 4 32 B2.72 ID_MMFR0_EL1, AArch32 Memory Model Feature
Register 0, EL1 on page B2-246
ID_MMFR1_EL1 3 c0 0 c1 5 32 B2.73 ID_MMFR1_EL1, AArch32 Memory Model Feature
Register 1, EL1 on page B2-248
ID_MMFR2_EL1 3 c0 0 c1 6 32 B2.74 ID_MMFR2_EL1, AArch32 Memory Model Feature
Register 2, EL1 on page B2-250
ID_MMFR3_EL1 3 c0 0 c1 7 32 B2.75 ID_MMFR3_EL1, AArch32 Memory Model Feature
Register 3, EL1 on page B2-252
ID_MMFR4_EL1 3 c0 0 c2 6 32 B2.76 ID_MMFR4_EL1, AArch32 Memory Model Feature
Register 4, EL1 on page B2-254
ID_PFR0_EL1 3 c0 0 c1 0 32 B2.77 ID_PFR0_EL1, AArch32 Processor Feature Register 0,
EL1 on page B2-256
ID_PFR1_EL1 3 c0 0 c1 1 32 B2.78 ID_PFR1_EL1, AArch32 Processor Feature Register 1,
EL1 on page B2-258
ID_PFR2_EL1 3 c0 0 c3 4 32 B2.79 ID_PFR2_EL1, AArch32 Processor Feature Register 2,
EL1 on page B2-260
ID_AA64DFR0_EL1 3 c0 0 c5 0 64 B2.54 ID_AA64DFR0_EL1, AArch64 Debug Feature Register 0,
EL1 on page B2-216
ID_AA64ISAR0_EL1 3 c0 0 c6 0 64 B2.56 ID_AA64ISAR0_EL1, AArch64 Instruction Set Attribute
Register 0, EL1 on page B2-219
ID_AA64ISAR1_EL1 3 c0 0 c6 1 64 B2.57 ID_AA64ISAR1_EL1, AArch64 Instruction Set Attribute
Register 1, EL1 on page B2-221
ID_AA64MMFR0_EL1 3 c0 0 c7 0 64 B2.58 ID_AA64MMFR0_EL1, AArch64 Memory Model Feature
Register 0, EL1 on page B2-222
ID_AA64MMFR1_EL1 3 c0 0 c7 1 64 B2.59 ID_AA64MMFR1_EL1, AArch64 Memory Model Feature
Register 1, EL1 on page B2-224
B2 AArch64 system registers
B2.2 AArch64 architectural system register summary
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
B2-129
Non-Confidential

ARM Cortex-A76 Core Specifications

General

Architecture	ARMv8.2-A
Microarchitecture	Cortex-A76
Pipeline Depth	13 stages
Frequency	Up to 3.0 GHz
Process Technology	7nm
Core Type	Out-of-order
NEON	Yes
Power Efficiency	Improved over Cortex-A75
Performance Improvement	35% over Cortex-A75
Core Count	1-4 cores per cluster
ISA Support	AArch64 and AArch32
Branch Prediction	Yes
L1 Data Cache	32KB, per core
L2 Cache	256KB or 512KB, per core
L3 Cache	Up to 4MB
Memory Support	LPDDR4, LPDDR4X, DDR4
DynamIQ Shared Unit (DSU)	DynamIQ Shared Unit (DSU)
Cryptography Extensions	Yes
Virtualization Support	Yes
L1 Cache	64 KB per core
