ARM Cortex-A76 Core User Manual

Table B2-5 Cluster registers (continued)
Name Copro CRn Opc1 CRm Opc2 Width Description
CLUSTERPMCLAIMSET_EL1 3 c15 0 c6 6 32-bit Cluster Performance Monitor Claim Tag Set
Register
CLUSTERPMCLAIMCLR_EL1 3 c15 0 c6 7 32-bit Cluster Performance Monitor Claim Tag Clear
Register
Security
Name Type Description
ACTLR_EL3 RW
B2.7 ACTLR_EL3, Auxiliary Control Register, EL3 on page B2-147
AFSR0_EL3 RW
B2.10 AFSR0_EL3, Auxiliary Fault Status Register 0, EL3 on page B2-151
AFSR1_EL3 RW
B2.13 AFSR1_EL3, Auxiliary Fault Status Register 1, EL3 on page B2-154
AMAIR_EL3 RW
B2.17 AMAIR_EL3, Auxiliary Memory Attribute Indirection Register, EL3 on page B2-158
CPTR_EL3 RW
B2.22 CPTR_EL3, Architectural Feature Trap Register, EL3 on page B2-165
MDCR_EL3 RW
B2.83 MDCR_EL3, Monitor Debug Configuration Register, EL3 on page B2-264
Reset management registers
Name Type Description
RMR_EL3 RW
B2.88 RMR_EL3, Reset Management Register on page B2-271
RVBAR_EL3 RW
B2.89 RVBAR_EL3, Reset Vector Base Address Register, EL3 on page B2-272
Address registers
Name Type Description
PAR_EL1 RW
B2.86 PAR_EL1, Physical Address Register, EL1 on page B2-269
B2 AArch64 system registers
B2.4 AArch64 registers by functional group
