ARM Cortex-A76 Core User Manual

The following table shows the 32-bit wide implementation defined Cluster registers. Details of these
registers can be found in Arm
®
DynamIQ
™
Shared Unit Technical Reference Manual
Table B2-5 Cluster registers
Name Copro CRn Opc1 CRm Opc2 Width Description
CLUSTERCFR_EL1 3 c15 0 c3 0 32-bit Cluster configuration register.
CLUSTERIDR_EL1 3 c15 0 c3 1 32-bit Cluster main revision ID.
CLUSTEREVIDR_EL1 3 c15 0 c3 2 32-bit Cluster ECO ID.
CLUSTERACTLR_EL1 3 c15 0 c3 3 32-bit Cluster auxiliary control register.
CLUSTERECTLR_EL1 3 c15 0 c3 4 32-bit Cluster extended control register.
CLUSTERPWRCTLR_EL1 3 c15 0 c3 5 32-bit Cluster power control register.
CLUSTERPWRDN_EL1 3 c15 0 c3 6 32-bit Cluster power down register.
CLUSTERPWRSTAT_EL1 3 c15 0 c3 7 32-bit Cluster power status register.
CLUSTERTHREADSID_EL1 3 c15 0 c4 0 32-bit Cluster thread scheme ID register.
CLUSTERACPSID_EL1 3 c15 0 c4 1 32-bit Cluster ACP scheme ID register.
CLUSTERSTASHSID_EL1 3 c15 0 c4 2 32-bit Cluster stash scheme ID register.
CLUSTERPARTCR_EL1 3 c15 0 c4 3 32-bit Cluster partition control register.
CLUSTERBUSQOS_EL1 3 c15 0 c4 4 32-bit Cluster bus QoS control register.
CLUSTERL3HIT_EL1 3 c15 0 c4 5 32-bit Cluster L3 hit counter register.
CLUSTERL3MISS_EL1 3 c15 0 c4 6 32-bit Cluster L3 miss counter register.
CLUSTERTHREADSIDOVR_EL1 3 c15 0 c4 7 32-bit Cluster thread scheme ID override register
CLUSTERPMCR_EL1 3 c15 0 c5 0 32-bit Cluster Performance Monitors Control Register
CLUSTERPMCNTENSET_EL1 3 c15 0 c5 1 32-bit Cluster Count Enable Set Register
CLUSTERPMCNTENCLR_EL1 3 c15 0 c5 2 32-bit Cluster Count Enable Clear Register
CLUSTERPMOVSSET_EL1 3 c15 0 c5 3 32-bit Cluster Overflow Flag Status Set
CLUSTERPMOVSCLR_EL1 3 c15 0 c5 4 32-bit Cluster Overflow Flag Status Clear
CLUSTERPMSELR_EL1 3 c15 0 c5 5 32-bit Cluster Event Counter Selection Register
CLUSTERPMINTENSET_EL1 3 c15 0 c5 6 32-bit Cluster Interrupt Enable Set Register
CLUSTERPMINTENCLR_EL1 3 c15 0 c5 7 32-bit Cluster Interrupt Enable Clear Register
CLUSTERPMXEVTYPER_EL1 3 c15 0 c6 1 32-bit Cluster Selected Event Type and Filter Register
CLUSTERPMXEVCNTR_EL1 3 c15 0 c6 2 32-bit Cluster Selected Event Counter Register
Reserved/RAZ 3 c15 0 c6 3 32-bit Cluster Monitor Debug Configuration Register
CLUSTERPMCEID0_EL1 3 c15 0 c6 4 32-bit Cluster Common Event Identification ID0
Register
CLUSTERPMCEID1_EL1 3 c15 0 c6 5 32-bit Cluster Common Event Identification ID1
Register
B2 AArch64 system registers
B2.4 AArch64 registers by functional group
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
B2-142
Non-Confidential

ARM Cortex-A76 Core Specifications

General

Architecture	ARMv8.2-A
Microarchitecture	Cortex-A76
Pipeline Depth	13 stages
Frequency	Up to 3.0 GHz
Process Technology	7nm
Core Type	Out-of-order
NEON	Yes
Power Efficiency	Improved over Cortex-A75
Performance Improvement	35% over Cortex-A75
Core Count	1-4 cores per cluster
ISA Support	AArch64 and AArch32
Branch Prediction	Yes
L1 Data Cache	32KB, per core
L2 Cache	256KB or 512KB, per core
L3 Cache	Up to 4MB
Memory Support	LPDDR4, LPDDR4X, DDR4
DynamIQ Shared Unit (DSU)	DynamIQ Shared Unit (DSU)
Cryptography Extensions	Yes
Virtualization Support	Yes
L1 Cache	64 KB per core
