ARM Cortex-A76 Core User Manual

Table D3-1 Memory-mapped debug register summary (continued)
Offset Name Type Width Description
0xFD4-0xFDC
EDPIDR5-7 RO 32 D3.13 EDPIDRn, External Debug Peripheral Identification Registers
5-7 on page D3-431
0xFE0
EDPIDR0 RO 32 D3.8 EDPIDR0, External Debug Peripheral Identification Register 0
on page D3-426
0xFE4
EDPIDR1 RO 32 D3.9 EDPIDR1, External Debug Peripheral Identification Register 1
on page D3-427
0xFE8
EDPIDR2 RO 32 D3.10 EDPIDR2, External Debug Peripheral Identification Register 2
on page D3-428
0xFEC
EDPIDR3 RO 32 D3.11 EDPIDR3, External Debug Peripheral Identification Register 3
on page D3-429
0xFF0
EDCIDR0 RO 32 D3.2 EDCIDR0, External Debug Component Identification Register 0
on page D3-420
0xFF4
EDCIDR1 RO 32 D3.3 EDCIDR1, External Debug Component Identification Register 1
on page D3-421
0xFF8
EDCIDR2 RO 32 D3.4 EDCIDR2, External Debug Component Identification Register 2
on page D3-422
0xFFC
EDCIDR3 RO 32 D3.5 EDCIDR3, External Debug Component Identification Register 3
on page D3-423
D3 Memory-mapped debug registers
D3.1 Memory-mapped debug register summary
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
D3-419
Non-Confidential

ARM Cortex-A76 Core Specifications

General

Architecture	ARMv8.2-A
Microarchitecture	Cortex-A76
Pipeline Depth	13 stages
Frequency	Up to 3.0 GHz
Process Technology	7nm
Core Type	Out-of-order
NEON	Yes
Power Efficiency	Improved over Cortex-A75
Performance Improvement	35% over Cortex-A75
Core Count	1-4 cores per cluster
ISA Support	AArch64 and AArch32
Branch Prediction	Yes
L1 Data Cache	32KB, per core
L2 Cache	256KB or 512KB, per core
L3 Cache	Up to 4MB
Memory Support	LPDDR4, LPDDR4X, DDR4
DynamIQ Shared Unit (DSU)	DynamIQ Shared Unit (DSU)
Cryptography Extensions	Yes
Virtualization Support	Yes
L1 Cache	64 KB per core
