ARM Cortex-A76 Core User Manual

Table B2-1 Registers with implementation defined bit fields (continued)
Name Op0 CRn Op1 CRm Op2 Width Description
TTBR1_EL2 3 c2 4 c0 1 64 B2.100 TTBR1_EL2, Translation Table Base Register 1, EL2
on page B2-285
VDISR_EL2 3 c12 4 c1 1 64 B2.101 VDISR_EL2, Virtual Deferred Interrupt Status Register,
EL2 on page B2-286
VSESR_EL2 3 c5 4 c2 3 64 B2.102 VSESR_EL2, Virtual SError Exception Syndrome
Register on page B2-287
VTCR_EL2 3 c2 4 c1 2 32 B2.103 VTCR_EL2, Virtualization Translation Control Register,
EL2 on page B2-288
VTTBR_EL2 3 c2 4 c1 0 64 B2.104 VTTBR_EL2, Virtualization Translation Table Base
Register, EL2 on page B2-289
Table B2-2 Other architecturally defined registers
Name Op0 CRn Op1 CRm Op2 Widt
h
Description
AFSR0_EL12 3 c5 5 1 0 32 Auxiliary Fault Status Register 0
AFSR1_EL12 3 c5 5 1 1 32 Auxiliary Fault Status Register 1
AMAIR_EL12 3 c10 5 c3 0 64 Auxiliary Memory Attribute Indirection Register
CNTFRQ_EL0 3 c14 3 0 0 32 Counter-timer Frequency register
CNTHCTL_EL2 3 c14 4 c1 0 32 Counter-timer Hypervisor Control register
CNTHP_CTL_EL2 3 c14 4 c2 1 32 Counter-timer Hypervisor Physical Timer Control
register
CNTHP_CVAL_EL2 3 c14 4 c2 2 64 Counter-timer Hyp Physical CompareValue register
CNTHP_TVAL_EL2 3 c14 4 c2 0 32 Counter-timer Hyp Physical Timer TimerValue register
CNTHV_CTL_EL2 3 c14 4 c3 1 32 Counter-timer Virtual Timer Control register
CNTHV_CVAL_EL2 3 c14 4 c3 2 64 Counter-timer Virtual Timer CompareValue register
CNTHV_TVAL_EL2 3 c14 4 c3 0 32 Counter-timer Virtual Timer TimerValue register
CNTKCTL_EL1 3 c14 0 c1 0 32 Counter-timer Kernel Control register
CNTKCTL_EL12 3 c14 5 c1 0 32 Counter-timer Kernel Control register
CNTP_CTL_EL0 3 c14 3 c2 1 32 Counter-timer Physical Timer Control register
CNTP_CTL_EL02 3 c14 5 c2 1 32 Counter-timer Physical Timer Control register
CNTP_CVAL_EL0 3 c14 3 c2 2 64 Counter-timer Physical Timer CompareValue register
CNTP_CVAL_EL02 3 c14 5 c2 2 64 Counter-timer Physical Timer CompareValue register
CNTP_TVAL_EL0 3 c14 3 c2 0 32 Counter-timer Physical Timer TimerValue register
CNTP_TVAL_EL02 3 c14 5 c2 0 32 Counter-timer Physical Timer TimerValue register
CNTPCT_EL0 3 c14 3 c0 1 64 Counter-timer Physical Count register
CNTPS_CTL_EL1 3 c14 7 c2 1 32 Counter-timer Physical Secure Timer Control register
CNTPS_CVAL_EL1 3 c14 7 c2 2 64 Counter-timer Physical Secure Timer CompareValue
register
B2 AArch64 system registers
B2.2 AArch64 architectural system register summary
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
B2-131
Non-Confidential

ARM Cortex-A76 Core Specifications

General

Architecture	ARMv8.2-A
Microarchitecture	Cortex-A76
Pipeline Depth	13 stages
Frequency	Up to 3.0 GHz
Process Technology	7nm
Core Type	Out-of-order
NEON	Yes
Power Efficiency	Improved over Cortex-A75
Performance Improvement	35% over Cortex-A75
Core Count	1-4 cores per cluster
ISA Support	AArch64 and AArch32
Branch Prediction	Yes
L1 Data Cache	32KB, per core
L2 Cache	256KB or 512KB, per core
L3 Cache	Up to 4MB
Memory Support	LPDDR4, LPDDR4X, DDR4
DynamIQ Shared Unit (DSU)	DynamIQ Shared Unit (DSU)
Cryptography Extensions	Yes
Virtualization Support	Yes
L1 Cache	64 KB per core
