Table B2-2 Other architecturally defined registers (continued)

Name Op0 CRn Op1 CRm Op2 Widt

Description

CNTPS_TVAL_EL1 3 c14 7 c2 0 32 Counter-timer Physical Secure Timer TimerValue register

CNTV_CTL_EL0 3 c14 3 c3 1 32 Counter-timer Virtual Timer Control register

CNTV_CTL_EL02 3 c14 5 c3 1 32 Counter-timer Virtual Timer Control register

CNTV_CVAL_EL0 3 c14 3 c3 2 64 Counter-timer Virtual Timer CompareValue register

CNTV_CVAL_EL02 3 c14 5 c3 2 64 Counter-timer Virtual Timer CompareValue register

CNTV_TVAL_EL0 3 c14 3 c3 0 32 Counter-timer Virtual Timer TimerValue register

CNTV_TVAL_EL02 3 c14 5 c3 0 32 Counter-timer Virtual Timer TimerValue register

CNTVCT_EL0 3 c14 3 c0 2 64 Counter-timer Virtual Count register

CNTVOFF_EL2 3 c14 4 c0 3 64 Counter-timer Virtual Offset register

CONTEXTIDR_EL1 3 c13 0 c0 1 32 Context ID Register (EL1)

CONTEXTIDR_EL12 3 c13 5 c0 1 32 Context ID Register (EL12)

CONTEXTIDR_EL2 3 c13 4 c0 1 32 Context ID Register (EL2)

CPACR_EL12 3 c1 5 c0 2 32 Architectural Feature Access Control Register

CPTR_EL3 3 c1 6 c1 2 32 Architectural Feature Trap Register (EL3)

DACR32_EL2 3 c3 4 c0 0 32 Domain Access Control Register

ESR_EL12 3 c5 5 c2 0 32 Exception Syndrome Register (EL12)

FAR_EL1 3 c6 0 c0 0 64 Fault Address Register (EL1)

FAR_EL12 3 c6 5 c0 0 64 Fault Address Register (EL12)

FAR_EL2 3 c6 4 c0 0 64 Fault Address Register (EL2)

FAR_EL3 3 c6 6 c0 0 64 Fault Address Register (EL3)

FPEXC32_EL2 3 c5 4 c3 0 32 Floating-point Exception Control register

HPFAR_EL2 3 c6 4 c0 4 64 Hypervisor IPA Fault Address Register

HSTR_EL2 3 c1 4 c1 3 32 Hypervisor System Trap Register

ID_AA64AFR0_EL1 3 c0 0 c5 4 64 AArch64 Auxiliary Feature Register 0

ID_AA64AFR1_EL1 3 c0 0 c5 5 64 AArch64 Auxiliary Feature Register 1

ID_AA64DFR1_EL1 3 c0 0 c5 1 64 AArch64 Debug Feature Register 1

ID_AA64PFR1_EL1 3 c0 0 c4 1 64 AArch64 Core Feature Register 1

ISR_EL1 3 c12 0 c1 0 32 Interrupt Status Register

LOREA_EL1 3 c10 0 c4 1 64 LORegion End Address Register

LORSA_EL1 3 c10 0 c4 0 64 LORegion Start Address Register

MAIR_EL1 3 c10 0 c2 0 64 Memory Attribute Indirection Register (EL1)

MAIR_EL12 3 c10 5 c2 0 64 Memory Attribute Indirection Register (EL12)

MAIR_EL2 3 c10 4 c2 0 64 Memory Attribute Indirection Register (EL2)

MAIR_EL3 3 c10 6 c2 0 64 Memory Attribute Indirection Register (EL3)

B2 AArch64 system registers

B2.2 AArch64 architectural system register summary

reserved.

B2-132

Non-Confidential
