Table A6-16 L1 data TLB location encoding
Bit fields of Rd Description
[31:24] RAMID = 0x0A
[23:6] Reserved
[5:0] TLB Entry (0->47)
Data cache reads return 64 bits of data in Data Register 0, Data Register 1, and Data Register 2. If cache
protection is supported, Data Register 2 is used to report ECC information using the format shown in the
following tables.
The following table shows the data that is returned from accessing the L1 data cache tag RAM with
ECC.
Table A6-17 L1 data cache tag format with ECC
Register Bit field Description
Data Register 0 [63:41] 0
[40:34] ECC
[33] Non-secure identifier for the physical
address
[32:5] Physical address [39:12]
[4:3] Reserved
[2] Transient/WBNA
[1:0]
MESI
00 Invalid
01 Shared
10 Exclusive
11 Modified with respect to the L2
cache
Data Register 1 [63:0] 0
Data Register 2 [63:0] 0
The following table shows the data that is returned from accessing the L1 data cache tag RAM without
ECC.
A6 Level 1 memory system
A6.6 Direct access to internal memory
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
A6-86
Non-Confidential
