Table A6-26 L2 tag format with a 256KB L2 cache size
Register Bit field Description
Data Register 0
[63:44]
0
[43:37] ECC [6:0] if configured with ECC for a
256KB L2 cache size, otherwise 0
[36:12] Physical address [39:15]
[11] Non-secure identifier for the physical
address
[10:9] Virtual index [13:12]
[8:6] Reserved
[5] Shareable
[4] Outer allocation hint
[3] L1 data cache valid
[2:0]
L2 State
101 Modified
001 Exclusive
x11 Shared
xx0 Invalid
Data Register 1 [63:0] 0
Data Register 2 [63:0] 0
The following table shows the data that is returned from accessing the L2 tag RAM when L2 is
configured with a 512KB cache size.
A6 Level 1 memory system
A6.6 Direct access to internal memory
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
A6-91
Non-Confidential
