Sel 411L - Page 1004

P.17.2
SEL-411L Relay Protection Manual Date Code 20151029
Analog Quantities
Quantities Listed Alphabetically
3PD Demand three-phase real power Megawatts [MW] (primary)
3PF Three-phase power factor
3PPKD Peak demand three-phase real power Megawatts [MW] (primary)
3PSHOT Present value of three-pole shot counter NA
3Q_F Fundamental reactive three-phase power Megavars [MVAr] (primary)
3QD Demand three-phase reactive power Megavars [MVAr] (primary)
3QPKD Peak demand three-phase reactive power Megavars [MVAr] (primary)
3S_F Fundamental apparent three-phase power Megavoltamps [MVA]
(primary)
3U Apparent three-phase power Megavoltamps [MVA]
(primary)
3UD Demand three-phase apparent power Megavoltamps [MVA]
primary)
3UPKD Peak demand three-phase apparent power Megavoltamps [MVA]
(primary)
3V0A 10-cycle average zero-sequence voltage (ang) Degrees [°] (±180°)
3V0FIA Zero-sequence instantaneous voltage angle Degrees [°] (±180°)
3V0FIM Zero-sequence instantaneous voltage magnitude Volts [V] (secondary)
3V0M 10-cycle average zero-sequence voltage (mag) Kilo-volts [kV] (primary)
3V0YFA Terminal Y, zero-sequence filtered voltage, angle Degrees [°] (±180°)
3V0YFI Terminal Y, zero-sequence filtered voltage, imaginary component Volts [V] (secondary)
3V0YFM Terminal Y, zero-sequence filtered voltage, magnitude Volts [V] (secondary)
3V0YFR Terminal Y, zero-sequence filtered voltage, real component Volts [V] (secondary)
3V0ZFA Terminal Z, zero-sequence filtered voltage, angle Degrees [°] (±180°)
3V0ZFI Terminal Z, zero-sequence filtered voltage, imaginary component Volts [V] (secondary)
3V0ZFM Terminal Z, zero-sequence filtered voltage, magnitude Volts [V] (secondary)
3V0ZFR Terminal Z, zero-sequence filtered voltage, real component Volts [V] (secondary)
3V2A 10-cycle average negative-sequence voltage angle Degrees [°] (±180°)
3V2FIA Negative-sequence instantaneous voltage angle Degrees [°] (±180°)
3V2FIM Negative-sequence instantaneous voltage magnitude Volts [V] (secondary)
3V2M 10-cycle average negative-sequence voltage magnitude Kilo-volts [kV] (primary)
3VA2YFA Terminal Y, negative-sequence filtered voltage, angle Degrees [°] (±180°)
3VA2YFI Terminal Y, negative-sequence filtered voltage, imaginary component Volts [V] (secondary)
3VA2YFM Terminal Y, negative-sequence filtered voltage, magnitude Volts [V] (secondary)
3VA2YFR Terminal Y, negative-sequence filtered voltage, real component Volts [V] (secondary)
3VA2ZFA Terminal Z, negative-sequence filtered voltage, angle Degrees [°] (±180°)
3VA2ZFI Terminal Z, negative-sequence filtered voltage, imaginary component Volts [V] (secondary)
3VA2ZFM Terminal Z, negative-sequence filtered voltage, magnitude Volts [V] (secondary)
3VA2ZFR Terminal Z, negative-sequence filtered voltage, real component Volts [V] (secondary)
51P01–51P10 51 elements pickup value Amps [A] (secondary)
51TD01–51TD10 51 elements time dial setting NA
87APAA, 87APAB,
87APAC
Angle of the equivalent Alpha Plane, A-phase, B-phase, C-phase Degrees [°] (±180°)
Table 17.1 Alphabetical List of Analog Quantities (Sheet 2 of 19)
Analog Quantities Phase, Phase-to-Phase and Sequence Quantities Units
