P.6.3
Date Code 20151029 Protection Manual SEL-411L Relay
PC Software
ACSELERATOR QuickSet Setup
ACSELERATOR QuickSet Setup
Follow the steps outlined in Section 2: Installation to prepare the relay for use.
Perform the following steps to initiate communications.
Step 1. Connect the appropriate communications cable between the
relay and the PC.
Step 2. Apply power to the relay.
Step 3. Start
ACSELERATOR QuickSet.
When
ACSELERATOR QuickSet starts, the initial screen presents the following
icons.
New—Create new settings for a connected or unconnected device
Read—Read settings from a connected device
Open—Open previously saved settings
Communications Parameters—Configure serial and network
connections
Manage Databases—Manage offline settings and databases
Update—Install and update
ACSELERATOR QuickSet software and
drivers
The functions represented by these six icons are also included in the menu
items. See the discussions of the individual menu items in this section for a
description of these functions.
Communications
Parameters
ACSELERATOR QuickSet can communicate with a relay via any relay serial
port set to SEL protocol, via the front-panel USB port, or via Ethernet.
Perform the following steps to configure
ACSELERATOR QuickSet to
communicate with the relay.
Step 1. Select Communications > Parameters from the
ACSELERATOR QuickSet main menu bar to open the
Communication Parameters dialog box, or select
Communications > Parameters from the startup screen.
Communications
➤ Connect—Request ACSELERATOR QuickSet to attempt to connect to a device using the current Connection
Parameters
➤ Parameters—Modify the Communications Parameters, including connection type (Serial, Network, or
Modem), PC port numbers, speed, and settings, device passwords, IP addresses, ports, and file transfer
options, and modem phone numbers and speeds.
➤ Network Address Book—Select from a list of Ethernet-connected devices. Add or modify devices by
specifying the Connection Name, IP Address, Telnet Port Number, User ID, and Password.
➤ Terminal—Open terminal window to issue ASCII commands directly to a connected relay.
➤ Logging—Initiate terminal logging to record terminal communications. View and clear the connection log.
Tools
➤ Settings—Convert settings between settings versions. Import and export settings from and to text files.
➤ HMI—Open HMI for connected device and manage custom HMI Device Overviews.
➤ Events—Collect event and view reports from connected devices.
➤ Options—Control ACSELERATOR QuickSet options, including Setting Comments, Event Viewer, and
Terminal Options.
➤ Firmware Loader—Upgrade relay firmware.
Help
➤ Access program and settings help
Ta b l e 6 . 3
ACSELERATOR QuickSet Submenu Options (Sheet 2 of 2)
