Sel 411L - Table 15.164 TIME Q Command; Table 15.165 TIME DST Command; Table 15.166 TRI Command

P.15.62
SEL-411L Relay Protection Manual Date Code 20151029
ASCII Command Reference
Description of Commands
Use the TIME hh:mm and TIME hh:mm:ss commands to set the relay
internal clock time. The value hh is for hours from 0–23; the value mm is for
minutes from 0–59; the value ss is for seconds from 0–59. If you enter a valid
time, the relay updates and saves the time in the nonvolatile clock, and
displays the time you just entered. If you enter an invalid time, the relay
responds,
Invalid Time.
TIME Q
The TIME Q command returns detailed information on the relay internal
clock. Use this command to query the status of high-accuracy time source
inputs and the present clock time mode.
When you issue the TIME Q command, the relay reports statistics on the
relay time sources. These statistics include the present time source and the last
time value update source (see Configuring High-Accuracy Timekeeping on
page P.13.1).
TIME DST
In response to the TIME DST command, the relay displays local time, UTC
time and UTC Offset, followed by daylight-savings time rules and
information.
=>>TIME DST<Enter>
local: 11:28:19 UTC: 18:28:19 UTC Offset: -07.0 hrs
Daylight Savings Time Begin Rule: 2nd Sunday of March at 02:00
Daylight Savings Time End Rule: 1st Sunday of November at 02:00
Daylight Savings Time Presently Active
Next Daylight Savings Time Beginning: 03/11/2012 02:00
Next Daylight Savings Time Ending: 11/06/2011 02:00
=>>
TRIGGER
The TRIGGER command initiates data captures for high-resolution
oscillography and event reports. For information on high-resolution
oscillography and event reports.
TRI
Use the TRI command to trigger the relay to record data for high-resolution
oscillography and event reports.
When you issue the TRI command, the relay responds,
Triggered. If the
event did not trigger within 1 second, the relay responds,
Did not trigger.
Table 15.164 TIME Q Command
Command Description Access Level
TIME Q Display detailed information about the internal relay
clock; query relay time.
1, B, P, A, O, 2
Table 15.165 TIME DST Command
Command Description Access Level
TIME DST Daylight-savings time rules and information 1, B, P, A, O
Table 15.166 TRI Command
Command Description Access Level
TRI Trigger relay data capture. 1, B, P, A, O, 2
