Sel 411L - Table 5.46 87 L Channel Monitoring Settings; Table 5.47 87 L Communications Bits Debounce Time Delay-Serial Communication

P.5.24
SEL-411L Relay Protection Manual Date Code 20151029
Settings
Port Settings
The serial and Ethernet communications bits are mutually exclusive.
Table 5.47 shows the debounce settings of the communications bits for serial
communications (E87CH = 2SS, 2SD, 3SM, or 3SS) and Table 5.48 shows
the debounce settings of the communications bits for Ethernet
communications (E87CH = 2E, 3E, or 4E).
e
This setting is hidden if E87CH = 2E, 3E, 4E or if E87CH = (2SS, 3SS) and 87PCH = 2.
f
This setting is hidden if E87CH = 2E, 3E, 4E or if E87CH = (2SS, 3SS) and 87PCH = 1.
g
This setting is available if Channel 1 contains a EIA-422 serial card; and E87CH = 3SM, 2E, 3E, 4E.
h
This setting is available if Channel 1 does not support the C37.94 protocol, or E87CH = 2E, 3E or 4E (forced to E).
i
This setting is available if Channel 2 does not support the C37.94 protocol, or E87CH = 2E, 3E or 4E (forced to E).
j
This setting is available only if E87CH= 2SD.
k
This setting is hidden if E87CH is not 2E, 3E, or 4E. Be sure the setting is a multicast address (high-byte must be 01).
l
Be sure to set 87LTMAC, 87LMAC1, 87LMAC2 and 87LMAC3 to unique values.
m
This setting is hidden if E87CH is not 3E or 4E. Be sure the setting is a multicast address (high-byte must be 01).
n
This setting is hidden if E87CH  4E.
o
This setting is hidden if E87CH is not 2E, 3E, or 4E.
p
This setting is hidden and forced to default if E87CH = 2E, 3E, or 4E.
Table 5.46 87L Channel Monitoring Settings
Label Prompt Default Value
87CH1SN
a
Data Sync Ch 1 (C-Channel based, T-Time based) C
87CH2SN
b
Data Sync Ch 2 (C-Channel based, T-Time based) C
87TFB
c
Time Fall Back Mode (1–4) 1
87CH1MT
d
Max. Round Trip Delay for Ch 1 (OFF, 1.0–50 ms) OFF
87CH1MD
d
Max. Step Change in Ch 1 Delay (OFF, 3.0–50 ms) OFF
87CH1MA
d
Max. Allowable Asym. for Ch 1 (OFF, 0.2–10 ms) OFF
87CH2MT
e
Max. Round Trip Delay for Ch 2 (OFF, 1.0–50 ms) OFF
87CH2MD
e
Max. Step Change in Ch 2 Delay (OFF, 3.0–50 ms) OFF
87CH2MA
e
Max. Allowable Asym. for Ch 2 (OFF, 0.2–10 ms) OFF
87CHTRG
f
87L Recording Trigger (SELOGIC Equation) 87LSP
87CHWP Enable Write Protect 87L Recording Files (Y, N) N
87CH1PC
g
Ch 1 Lost Packet Alarm Thres. (OFF, 1–2500) OFF
87CH2PC
h
Ch 2 Lost Packet Alarm Thres. (OFF, 1–2500) OFF
87CH3PC
i
Ch 3 Lost Packet Alarm Thres. (OFF, 1–2500)
a
This setting is hidden if E87CH = 2E, 3E or 4E, or if E87CH = 2SS or 3SS and 87PCH = 2.
b
This setting is hidden if E87CH = 2E, 3E or 4E, or if E87CH = 2SS or 3SS and 87PCH = 1.
c
This setting is hidden if 87CH1SN = C and 87CH2SN = C, or if E87CH = 2SS, 2SD, 3SM.
d
This setting is hidden if E87CH =2E, 3E or 4E, or if E87CH = 2SS, or 3SS and 87PCH = 2.
e
This setting is hidden if E87CH =2E, 3E or 4E, or if E87CH = 2SS or 3SS and 87PCH = 1.
f
This setting is hidden if E87CH =2E, 3E or 4E.
g
This setting is hidden if E87CH = 2SS or 3SS and 87PCH = 2.
h
This setting is hidden if E87CH = 2SS or 3SS and 87PCH = 1, or if E87CH = 2E.
i
This setting is hidden if E87CH = 4E.
Table 5.47 87L Communications Bits Debounce Time Delay—Serial Communication
Setting Description Default
87Rx1PU
a
a
These settings are hidden if Channel 1 (Port 1) is not active (87CH1AC = 0).
Received Bit x
b
, Port 1 pickup time (0–20 ms)
b
x = 1–4.
0
87Rx1DO
a
Received Bit x
b
, Port 1 dropout time (0–20 ms) 0
87Rx2PU
c
c
These settings are hidden if Channel 2 (Port 2) is not active (87CH2AC = 0).
Received Bit x
b
, Port 2 pickup time (0–20 ms) 0
87Rx2DO
c
Received Bit x
b
, Port 2 dropout time (0–20 ms) 0
