Settings
Global Settings
Make Table 5.9 settings for Interface Board #2 when Global enable setting
EICIS := Y.
Make Table 5.11 settings when Global enable setting EDRSTC := Y.
Table 5.9 Interface Board #2 Control Inputs
Label Prompt
Default
Value
IN301PU Input IN301 Pickup Delay (0.0000–5 cyc
a
)
a
If the interface board has more than eight input contacts, the upper range is 1 cycle.
0.1250
b
b
Set to Global setting IN3XXD when EICIS := N.
IN301DO Input IN301 Dropout Delay (0.0000–5 cyc
a
)0.1250
b
•
•
•
•
•
•
•
•
•
IN3mmPU
c
c
mm is the number of available input contacts on the interface board.
Input IN3mm
c
Pickup Delay (0.0000–5 cyc
a
)0.1250
b
IN3mmDO
c
Input IN3mm
c
Dropout Delay (0.0000–5 cyc
a
)0.1250
b
Table 5.10 Settings Group Selection
Label Prompt Default Value
SS1 Select Setting Group 1 (SELOGIC Equation) PB3 AND NOT SG1
SS2 Select Setting Group 2 (SEL
OGIC Equation) PB3 AND SG1
SS3 Select Setting Group 3 (SEL
OGIC Equation) 0
SS4 Select Setting Group 4 (SEL
OGIC Equation) 0
SS5 Select Setting Group 5 (SEL
OGIC Equation) 0
SS6 Select Setting Group 6 (SEL
OGIC Equation) 0
TGR Group Change Delay (0–54000 cycles) 180
Table 5.11 Data Reset Control
Label Prompt
Default
Value
RST_DEM Reset Demand Metering (SELOGIC Equation) NA
RST_PDM Reset Peak Demand Metering (SEL
OGIC Equation) NA
RST_ENE Reset Energy Metering (SEL
OGIC Equation) NA
RSTMML Reset Maximum/Minimum Line (SEL
OGIC Equation) NA
RSTMMB1 Reset Maximum/Minimum Breaker 1 (SEL
OGIC Equation) NA
RSTMMB2 Reset Maximum/Minimum Breaker 2 (SEL
OGIC Equation) NA
RST_BK1 Reset Monitoring Breaker 1 (SEL
OGIC Equation) NA
RST_BK2 Reset Monitoring Breaker 2 (SEL
OGIC Equation) NA
RST_BAT Reset Battery Monitoring (SEL
OGIC Equation) NA
RST_79C Reset Recloser Shot Count Accumulators (SEL
OGIC Equation) NA
RSTTRGT Target Reset (SEL
OGIC Equation) NA
RSTFLOC Reset Fault Locator (SEL
OGIC Equation) NA
RSTDNPE Reset DNP Fault Summary Data (SEL
OGIC Equation) TRGTR
RST_HAL Reset Warning Alarm Pulsing (SEL
OGIC Equation) NA
