P.7.4
SEL-411L Relay Protection Manual Date Code 20151029
Front-Panel Operations
Front-Panel Layout
Pressing the ESC pushbutton reverts the LCD display to the previous screen.
Pressing ESC repeatedly returns you to the
MAIN MENU. If a status warning,
alarm condition, or event condition is active (not acknowledged or reset), the
relay displays the full-screen status warning, alarm screen, or trip event screen
in place of the
MAIN MENU.
Screen Scrolling
The front panel has two screen scrolling modes: autoscrolling mode and
manual-scrolling mode. After front-panel time out, the LCD presents each of
the display screens in this sequence:
One-line diagram
Any active (filled) alarm points screens
Any active (filled) display points screens
Enabled metering screens
The relay displays enabled metering screens in the order listed in Table 7.2.
(see Figure 7.18 for samples of the metering screens). This sequence
comprises the
ROTATING DISPLAY.
Use the front-panel settings (the SET F command from a communications
port or the front-panel settings in
ACSELERATOR QuickSet) to access the
metering screen enables. Entering a Y (Yes) for a metering screen enable
setting causes the corresponding metering screen to appear in the
ROTATING
DISPLAY
. Entering an N (No) hides the metering screen from presentation in
the
ROTATING DISPLAY. Figure 7.4 shows a sample ROTATING DISPLAY
consisting of an example alarm points screen, an example display points
screen, and the two factory-default metering screens, RMS_I and FUND_VI
(the screen values in Figure 7.4 are representative values).
Table 7.2 Metering Screens Enable Settings
Name Description Range Default
ONELINE One Line Bay Control Diagram Y, N N
RMS_V RMS Line Voltage Screen Y, N N
RMS_I RMS Line Current Screen
a
a
The default displays are RMS_I and FUND_VI.
Y, N Y
RMS_VPP RMS Line Voltage Phase-to-Phase Screen Y, N N
RMS_W RMS Active Power Screen Y, N N
FUNDVAR Fundamental Reactive Power Screen Y, N N
RMS_VA RMS Apparent Power Screen Y, N N
RMS_PF RMS Power Factor Screen Y, N N
RMS_BK1 RMS Breaker 1 Currents Screen Y, N N
RMS_BK2 RMS Breaker 2 Currents Screen Y, N N
STA_BAT Station Battery Screen Y, N N
FUND_VI Fundamental Voltage and Current Screen
a
Y, N Y
FUNDSEQ Fundamental Sequence Quantities Screen Y, N N
FUND_BK Fundamental Breaker Currents Screen Y, N N
DIFF_L Differential Metering Local Currents Screen Y, N Y
DIFF_T Differential Metering Total Currents Screen Y, N Y
NOTE: The initial display can
present only the RMS_I line current
screen. This can occur when you have
not enabled any of the metering
screens, alarm points, and display
points.
