ASCII Command Reference
Description of Commands
COM RTC
Use the COM RTC to get a report on the status of the configured
synchrophasor client channels.
COM RTC c C and COM RTC c R
The COM RTC C and COM RTC R commands clear/reset the maximum
packet delay. The C and R options are identical.
CONTROL nn
Use the CONTROL nn command to set, clear, or pulse internal Relay Word
bits RB01–RB32 (Remote Bits 1–32). Remote bits in SEL
OGIC control
equations are similar to hardwired control inputs, in that you use these bits to
affect relay operation from outside sources. For control inputs, external input
to the relay comes through the rear panel; in the case of the CON nn
command, external control signals come through the communications ports.
See Control Points on page C.3.19 for information on remote bits.
COM A L date1
c
Display the records from MIRRORED BITS
communications Channel A on the date
date1.
1, B, P, A, O, 2
COM B L date1 date2
c
Display the records from MIRRORED BITS
communications Channel B between the
dates date1 and date2. The date listed first,
date1, is at the top of the report; the date
listed second, date2, is at the bottom of the
report.
1, B, P, A, O, 2
a
Parameter k indicates a specific number of communications buffer records.
b
Parameters m and n are communications buffer row numbers.
c
Enter date1 and date2 in the same format as Global setting DATE_F.
Table 15.34 COM c L Command (Sheet 2 of 2)
Command Description Access Level
Table 15.35 COM RTC c Command
Command
a
a
Parameter c is A, B, or absent for channel A, channel B, or all enabled channels, respectively.
Description Access Level
COM RTC Return a report describing the communications on
all enabled synchrophasor client channels.
1, B, P, A, O, 2
COM RTC A Return a report describing the communications on
synchrophasor client channel A.
1, B, P, A, O, 2
COM RTC B Return a report describing the communications on
synchrophasor client channel B.
1, B, P, A, O, 2
Table 15.36 COM RTC c C and COM RTC c R Command
Command Description Access Level
COM RTC C Clear/reset the maximum packet delay on all
enabled synchrophasor client channels.
P, A, O, 2
COM RTC A R Clear/reset the maximum packet delay on
synchrophasor client channel A.
P, A, O, 2
COM RTC B C Clear/reset the maximum packet delay on
synchrophasor client channel B.
P, A, O, 2
