Sel 411L - Figure 7.14 Invalid Password Screen

P.7.14
SEL-411L Relay Protection Manual Date Code 20151029
Front-Panel Operations
Front-Panel Menus and Screens
Figure 7.14 Invalid Password Screen
Main Menu
The MAIN MENU is the starting point for all other front-panel menus. The relay
MAIN MENU is shown in Figure 7.15. When the front-panel LCD is in the
ROTATING DISPLAY, press the ENT pushbutton to show the MAIN MENU.
Figure 7.15 MAIN MENU
Meter
The relay displays metering screens on the LCD. Highlight METER on the MAIN
MENU
screen to select these screens. The METER MENU, (an example is shown in
Figure 7.16), allows you to choose the following metering screens
corresponding to the relay metering modes:
Figure 7.16 METER MENU Screens
The Password Entered
Is Not Sufficient for
The Required Access
Level.
Password Invalid
METER
EVENTS
BREAKER MONITOR
RELAY ELEMENTS
LOCAL CONTROL
SET/SHOW
RELAY STATUS
VIEW CONFIGURATION
DISPLAY TEST
RESET ACCESS LEVEL
MAIN MENU
➤ RMS METER
➤ FUNDAMENTAL METER
➤ DEMAND METER (if enabled in group settings)
➤ ENERGY METER
➤ MAX/MIN
➤ SYNCHRONISM CHECK (if enabled in group settings)
➤ DIFFERENTIAL METER
a
a
Available when E87L = Y (group settings) and E87CH is enabled (Port 87 settings).
METER MENU METER MENU
Demand Meter Enabled
(EDEM := ROL or
EDEM := THM)
Synchronism Check Enabled
(E25BK1 := Y or
E25BK2 := Y)
Differential Meter Enabled
(E87CH enabled and E87L = Y)
No Synchronism Check
No Demand Metering
(E25BK1 := N)
(E25BK2 := N)
(EDEM := OFF)
No Differential Elements
(E87CH = N)
(E87L = N)
RMS METER
FUNDAMENTAL METER
ENERGY METER
MAX/MIN
RMS METER
FUNDAMENTAL METER
DEMAND METER
ENERGY METER
MAX/MIN
SYNCHRONISM CHECK
DIFFERENTIAL METER
