P.5.25
Date Code 20151029 Protection Manual SEL-411L Relay
Settings
DNP3 Settings—Custom Maps
DNP3 Settings—Custom Maps
Make Table 5.51 settings if preceding setting DNPBID := N.
Table 5.48 87L Communications Bits Debounce Time Delay—Ethernet Communication
Setting Description Default
87Rx1PU
a,b
a
These settings are hidden if E87CH is not 2E, 3E, or 4E.
b
x = 1–9.
Received Bit x, Peer 1 pickup time (0–20 ms) 0 ms
87Ryy1P
a,c
c
yy = 10–32.
Received Bit yy, Peer 1 pickup time (0–20 ms) 0 ms
87Rx2PU
a,b
Received Bit x, Peer 2 pickup time (0–20 ms) 0 ms
87Ryy2P
a,c
Received Bit yy, Peer 2 pickup time (0–20 ms) 0 ms
87Rx3PU
a,b
Received Bit x, Peer 3 pickup time (0–20 ms) 0 ms
87Ryy3P
a,c
Received Bit yy, Peer 3 pickup time (0–20 ms) 0 ms
87Rx1DO
a,b
Received Bit x, Peer 1 dropout time (0–20 ms) 0 ms
87Ryy1D
a,c
Received Bit yy, Peer 1 dropout time (0–20 ms) 0 ms
87Rx2DO
a,b
Received Bit x, Peer 2 dropout time (0–20 ms) 0 ms
87Ryy2D
a,c
Received Bit yy, Peer 2 dropout time (0–20 ms) 0 ms
87Rx3DO
a,b
Received Bit x, Peer 3 dropout time (0–20 ms) 0 ms
87Ryy3D
a,c
Received Bit yy, Peer 3 dropout time (0–20 ms) 0 ms
Table 5.49 DNP3 Settings Categories
Settings Reference
DNP3 Object Default Map Enables Table 5.50
Binary Input Map Table 5.51
Binary Output Map Table 5.52
Counter Map Table 5.53
Analog Input Map Table 5.54
Analog Output Map Table 5.55
DNP3 Fault Location Min and Max Table 5.56
Table 5.50 DNP3 Object Default Map Enables
Label Prompt Default Value
DNPBID Use default DNP map for Binary Inputs (Y, N) Y
DNPBOD Use default DNP map for Binary Outputs (Y, N) Y
DNPCOD Use default DNP map for Counters (Y, N) Y
DNPAID Use default DNP map for Analog Inputs (Y, N) Y
DNPAOD Use default DNP map for Analog Outputs (Y, N) Y
Table 5.51 Binary Input Map
Label Prompt Default Value
BI_n Binary Input label or 0 or 1. See Table 4.10.
NOTE: See corresponding command
descriptions SET D on page P.15.47
and SHO D on page P.15.50 to set or
show the DNP3 settings.
