P.15.49
Date Code 20151029 Protection Manual SEL-411L Relay
ASCII Command Reference
Description of Commands
SET R
Use the SET R command to set Report settings and to program SER points
and aliases. You can also set event report parameters and program event report
digital elements. There is only one instance for the Report settings.
SET T
Use the SET T command to set aliases for Relay Word bits and analog
quantities. There is only one instance for the alias settings.
SET TERSE
Use the TERSE option to inhibit the relay from sending the settings class or
instance readback when you end a settings session. SEL recommends that you
use the TERSE option sparingly; you should review the readback information
to confirm that you have entered the settings that you intended.
You can use the TERSE option in any SET command at any position after
typing SET. When you end the settings edit session, the relay responds,
Save
settings (Y,N)?
If you answer Y <Enter>, the relay pulses the Relay Word
bit SALARM, and responds,
Saving Settings, Please Wait............
The relay saves the new settings, then responds,
Settings Saved. If you
answer N <Enter> to the save settings prompt, the relay responds,
Settings
aborted
.
SHOW
The SHOW command shows the relay settings. When showing settings, the
relay displays the settings label and the present value from nonvolatile
memory.
The relay organizes settings in classes, instances, categories, and specific
settings; see SET for information on settings organization. The relay displays
each setting in the order specified in the settings tables. When you are using a
Ta b l e 1 5.1 25 S E T R Co m m an d
Command Description Access Level
SET R Set the Report relay settings, beginning at the
first setting for this class.
P, A, O, 2
SET R label Set the Report relay settings, beginning at the
settings label label.
P, A, O, 2
Tab l e 15.1 26 S E T T C o m m a n d
Command Description Access Level
SET T Set the alias settings. P, A, O, 2
Table 15.127 SET TERSE Command Examples
Command
a
a
TERSE may be entered as TE as shown in this example.
Description Access Level
SET TERSE SET Group relay settings for the active group,
beginning at the first setting in this instance;
omit settings readback.
P, 2
SET 3 TE label SET Group 3 settings, beginning at the settings
label label; omit settings readback.
P, 2
SET P p label
TERSE
Set the communications Port relay settings for
Port p, beginning at the settings label label;
omit readback.
P, A, O, 2
