Sel 411L - Table 15.16 CBR TERSE Command; Table 15.17 CEV Command; Table 15.18 CEV ACK Command

P.15.6
SEL-411L Relay Protection Manual Date Code 20151029
ASCII Command Reference
Description of Commands
CBR TERSE
The CBR TERSE command omits the breaker report labels.
CEVENT
The CEVENT command provides a Compressed ASCII response similar to
the EVENT command. See Section 2: SEL Communications Protocols in the
Communications Manual for information on the Compressed ASCII
command set. For detailed examples of the items in the Compressed ASCII
event report, see CEVENT on page P.8.24.
CEV
Use the CEV command to gather relay event reports. When parameter n is
1–9999, n indicates the order of the event report. The most recent event report
is 1, the next most recent report is 2, and so on. When parameter n is
10000–42767, n indicates the absolute serial number of the event report.
CEV ACK
Use CEV ACK to acknowledge viewing the oldest unacknowledged event on
the present communications port. View this event with the CEV NEXT or
EVE NEXT commands.
Table 15.16 CBR TERSE Command
Command
a
a
Parameter n = 1 or 2 to represent Circuit Breaker 1 and Circuit Breaker 2.
Description Access Level
CBR TERSE Return the most recent circuit breaker report
for Circuit Breaker 1 and Circuit Breaker 2 in
Compressed ASCII format; suppress the
labels; transmit only the data lines.
1, B, P, A, O, 2
CBR n TERSE Return the most recent circuit breaker report
for Circuit Breaker
n in Compressed ASCII
format; suppress the labels; transmit only the
data lines.
1, B, P, A, O, 2
Ta b l e 1 5.1 7 C E V Co m m a n d
Command
a
a
Parameter n indicates event order or serial number.
Description Access Level
CEV Return the most recent event report (including
settings and summary) at full length with 4-samples/
cycle data in Compressed ASCII format.
1, B, P, A, O, 2
CEV n Return particular n
event report (including settings
and summary) at full length with 4
-samples/cycle
data in Compressed ASCII format.
1, B, P, A, O, 2
Table 15.18 CEV ACK Command
Command Description Access Level
CEV ACK Acknowledge the oldest unacknowledged
event at the present communications port.
1, B, P, A, O, 2
