Front-Panel Operations
Front-Panel Menus and Screens
Figure 7.11 Fast Meter Display Points Sample Screen
Front-Panel Menus and Screens
Operate the relay front panel through a sequence of menus that you view on
the front-panel display. The
MAIN MENU is the introductory menu for other
front-panel menus (see Figure 7.3). These additional menus allow you on-site
access to metering, control, and settings for configuring the relay to your
specific application needs. Use the following menus and screens to set the
relay, perform local control actions, and read metering:
➤ Support Screens
➢ Contrast
➢ Password
➤ MAIN MENU
➢ METER
➢ EVENTS
➢ BREAKER MONITOR
➢ RELAY ELEMENTS
➢ LOCAL CONTROL
➢ SET/SHOW
➢ RELAY STATUS
➢ VIEW CONFIGURATION
➢ DISPLAY TEST
➢ RESET ACCESS LEVEL
➢ ONELINE DIAGRAM
Support Screens
The relay displays special screens over the top of the menu or screen that you
are using to control the relay or view data. These screens are the contrast
adjustment screen and the
PASSWORD REQUIRED screen.
Contrast
You can adjust the LCD screen contrast to suit your viewing angle and
lighting conditions. To change screen contrast, press and hold the ESC
pushbutton for one second. The relay displays a contrast adjustment box
superimposed over the display.
Figure 7.12 shows the contrast adjustment box with the
MAIN MENU screen in
the background. Pressing the Right Arrow pushbutton increases the contrast.
Pressing the Left Arrow pushbutton decreases the screen contrast. When
finished adjusting the screen contrast, press the ENT pushbutton.
FAST METER TEST!!!!
ROTATING DISPLAY
Press for menu
