P.4.8
SEL-411L Relay Protection Manual Date Code 20151029
Autoreclosing and Synchronism-Check
One-Circuit-Breaker Autoreclosing
Enable Autoreclose
Logic for One Circuit
Breaker
Three-Pole Trip Circuit Breaker
The initial settings necessary to enable autoreclose for a single three-pole trip
circuit breaker are shown in Table 4.2.
Single-Pole Trip Circuit Breaker
The initial settings necessary to enable autoreclose for one single-pole trip
circuit breaker are shown in Table 4.3.
Recloser Mode
Enables
The SELOGIC control equations E3PR1 and ESPR1 set the relay for the
autoreclose modes. Table 4.4 illustrates how to enable the autoreclose modes
for Circuit Breaker 1.
Table 4.2 One-Circuit-Breaker Three-Pole Reclose Initial Settings
Setting Description Entry
General Global Settings (Global)
NUMBK Number of Breakers in Scheme 1
Breaker Configuration (Breaker Monitor)
BK1TYP Breaker 1 Trip Type 3
Breaker 1 Inputs (Breaker Monitor)
52AA1 N/O Contact Input—BK1 (SELOGIC
®
control equation) NA
Relay Configuration (Group)
E79 Reclosing Y
Table 4.3 One-Circuit-Breaker Single-Pole Reclose Initial Settings
Setting Description Entry
General Global Settings (Global)
NUMBK Number of Breakers in Scheme 1
Breaker Configuration (Breaker Monitor)
BK1TYP Breaker 1 Trip Type 1
Breaker 1 Inputs (Breaker Monitor)
52AA1 A-phase N/O Contact Input—BK1 (SELOGIC Equation) NA
52AB1 B-phase N/O Contact Input—BK1 (SEL
OGIC Equation) 52AA1
52AC1 C-phase N/O Contact Input—BK1 (SEL
OGIC Equation) 52AA1
Relay Configuration (Group)
E79 Reclosing Y
Table 4.4 One Circuit Breaker Modes of Operation
E3PR1 ESPR1 Result
0 0 Autoreclose disabled
0 1 Single-pole autoreclose only enabled
1 0 Three-pole autoreclose only enabled
1 1 Single- and three-pole autoreclose enabled
