TARGET
The TARGET command displays the elements for a selected row in the Relay
Word bit table (see Section 16: Relay Word Bits).
TAR
Use the TAR command to view a row of Relay Word bit elements or aliases.
When using the TAR command, you can specify the row number or element
name.
The relay memorizes the latest target row input conditioned by your present
access level. The relay displays Row 0 if you have not specified a row since
the relay was turned on, the access level has timed out, or you have issued the
QUIT command.
If you specify the repeat count k at a number greater than 8, the relay displays
the repeated target rows on the terminal screen in groups of eight, with the
target row elements listed above each grouping.
TAR ALL
Use the TAR ALL command to display all of the relay targets.
TAR R
The TAR R command has two functions. Use this command to reset any
latched relay targets resulting from a tripping event. Also employ the TAR R
command to reset to Row 0 the memorized target row that the relay reports
when you issue a simple TAR command.
TAR X
Use the TAR X command to view a different target row in the Relay Word bit
table than the target row in the target row repeat memory. This function is
useful for relay testing. See Section 11: Testing and Troubleshooting for more
information.
Ta b l e 1 5.1 5 0 TA R Co m m a n d
Command
a
a
Parameter k is the repeat count from 1–32767.
Description Access Level
TAR Display target Row 0 or display the most
recently viewed target row.
1, B, P, A, O, 2
TAR n Display target Row n. 1, B, P, A, O, 2
TAR n k Display target Row n and repeat for k times;
the repeat count k must follow the row number.
1, B, P, A, O, 2
TAR name Display the target row with the element name
name.
1, B, P, A, O, 2
TAR name k Display the target row with the element name
name and repeat for k times; the repeat count k
can be before or after the name option.
1, B, P, A, O, 2
Table 15.151 TAR ALL Command
Command Description Access Level
TAR ALL Display all target rows. 1, B, P, A, O, 2
Ta b l e 1 5.1 52 TA R R C om m a n d
Command Description Access Level
TAR R Reset latched targets and return memorized
row to Row 0.
1, B, P, A, O, 2
