P.5.16
SEL-411L Relay Protection Manual Date Code 20151029
Settings
Front-Panel Settings
RMS_BK2 RMS Breaker 2 Currents Screen (Y, N) N
STA_BAT Station Battery Screen (Y, N) N
FUND_VI Fundamental Voltage and Current Screen (Y, N) Y
FUNDSEQ Fundamental Sequence Quantities Screen (Y, N) N
FUND_BK Fundamental Breaker Currents Screen (Y, N) N
DIFF_L Differential Metering Local Currents Screen (Y, N) Y
DIFF_T Differential Metering Total Currents Screen (Y, N) Y
a
Screens will not rotate when SCROLD := OFF; the first screen in the rotation order remains on
the screen.
Table 5.28 Selectable Operator Pushbuttons
Label Prompt
Default
Value
PB1_HMI Pushbutton 1 HMI Screen (OFF, AP, DP, EVE, SER, BC)
a, b
a
PBn_HMI can only be set to DP if a valid display point has been set.
b
Each instance (AP, DP, EVE, SER, BC) can only be set to a single operator pushbutton.
OFF = No HMI Pushbutton Operation
AP = Alarm Points
DP = Display Points
EVE = Event Summaries
SER = SER HMI Display
OFF
PB2_HMI Pushbutton 2 HMI Screen (OFF, AP, DP, EVE, SER, BC)
a, b
OFF
PB3_HMI Pushbutton 3 HMI Screen (OFF, AP, DP, EVE, SER, BC)
a, b
OFF
PB4_HMI Pushbutton 4 HMI Screen (OFF, AP, DP, EVE, SER, BC)
a, b
OFF
PB5_HMI Pushbutton 5 HMI Screen (OFF, AP, DP, EVE, SER, BC)
a, b
OFF
PB6_HMI Pushbutton 6 HMI Screen (OFF, AP, DP, EVE, SER, BC)
a, b
OFF
PB7_HMI Pushbutton 7 HMI Screen (OFF, AP, DP, EVE, SER, BC)
a, b
OFF
PB8_HMI Pushbutton 8 HMI Screen (OFF, AP, DP, EVE, SER, BC)
a, b
OFF
PB9_HMI Pushbutton 9 HMI Screen (OFF, AP, DP, EVE, SER, BC)
a, b
OFF
PB10HMI Pushbutton 10 HMI Screen (OFF, AP, DP, EVE, SER, BC)
a, b
OFF
PB11HMI Pushbutton 11 HMI Screen (OFF, AP, DP, EVE, SER, BC)
a, b
OFF
PB12HMI Pushbutton 12 HMI Screen (OFF, AP, DP, EVE, SER, BC)
a, b
OFF
Table 5.29 Front-Panel Event Display
Label Prompt
Default
Value
DISP_ER Enable HMI Auto Display of Events Summaries (Y, N) Y
TYPE_ER Types of Events for HMI Auto Display (ALL, TRIP)
a
a
Setting is only available if DISP_ER := Y.
ALL
NUM_ER Operator Pushbutton Events to Display (1–100)
b
b
Setting is only available if an operator pushbutton has been set to EVE.
10
Table 5.27 Selectable Screens for the Front Panel (Sheet 2 of 2)
Label Prompt Default Value
