P.15.52
SEL-411L Relay Protection Manual Date Code 20151029
ASCII Command Reference
Description of Commands
SHO N
Use the SHO N command to show notes in the relay.
SHO O
Use the SHO O command to show the Output SELOGIC control equations.
See Control Outputs on page P.2.6 for more information on relay control
outputs.
SHO P
Use the SHO P command to configure the relay communications ports; each
port is a settings instance. The relay communications ports include serial ports
at PORT F, PORT 1, PORT 2, and PORT 3. PORT 5 is the Ethernet card port in which
you can install the Ethernet card.
The SHO P command with no options and parameters shows the settings for
the active port.
Ta b l e 1 5.1 35 S H O M Co m ma n d
Command Description Access Level
SHO M Show the Breaker Monitor relay settings,
beginning at the first setting in this class.
1, B, P, A, O, 2
SHO M label Show the Breaker Monitor relay settings,
beginning at the settings label label.
1, B, P, A, O, 2
Table 15.136 SHO N Command
Command Description Access Level
SHO N Show notes in the relay. 1, B, P, A, O, 2
Ta b l e 1 5.1 37 S H O O Co m m a nd
Command Description Access Level
SHO O Show the Output SELOGIC control equation
relay settings, beginning at OUT101.
1, B, P, A, O, 2
SHO O label Show the Output SEL
OGIC control equation
relay settings, beginning at the output label
label.
1, B, P, A, O, 2
Table 15.138 SHO P Command
Command
a
a
Parameter p = 1–3, F, and 5 which corresponds to PORT 1–PORT 3, PORT F, and PORT 5.
Description Access Level
SHO P Show the relay settings for the port presently in
use, beginning at the first setting.
1, B, P, A, O, 2
SHO P label Show the relay settings for the port presently in
use, beginning at the settings label label.
1, B, P, A, O, 2
SHO P p Show the communications Port relay settings for
Port p, beginning at the first setting for this port.
1, B, P, A, O, 2
SHO P
p label Show the communications Port relay settings for
Port p, beginning at the settings label label.
1, B, P, A, O, 2
