Protection Free-Form SELOGIC Control Equations
Protection free-form SELOGIC control equations are in classes 1–6
corresponding to settings Groups 1–6 (see Section 14: SEL
OGIC Control
Equation Programming).
Table 5.18 only shows the factory default protection free-form SEL
OGIC
control equations. Up to 250 lines of free-form equations may be entered in
each of six settings groups, although the actual maximum capacity may be
less. See SEL
OGIC Control Equation Capacity on page P.14.10 for more
information.
Automation Free-Form SELOGIC Control Equations
Automation free-form SELOGIC control equations are in blocks 1–10 (see
Section 14: SEL
OGIC Control Equation Programming).
The relay does not contain any automation free-form SEL
OGIC settings in the
factory default settings.
The relay has a capacity of 100 lines of automation free-form SEL
OGIC
control equations in each of 10 automation setting blocks. See SEL
OGIC
Control Equation Capacity on page P.14.10 for more information.
Ta b l e 5.1 7 D N P3
Label Prompt
Default
Value
EVELOCK Event Summary Lock Period (0–1000 s) 0
DNPSRC DNP Session Time Base (LOCAL, UTC) UTC
Table 5.18 Protection Free-Form SELOGIC Control Equations
Label Default Value
PLT01S PB1_PUL AND NOT PLT01 # 87L ENABLED
PLT01R PB1_PUL AND PLT01
PLT02S PB2_PUL AND NOT PLT02 # COMM SCHEME ENABLED
PLT02R PB2_PUL AND PLT02
PLT04S PB4_PUL AND NOT PLT04 # RELAY TEST MODE
PLT04R PB4_PUL AND PLT04
PLT06S PB6_PUL AND NOT PLT06 # MANUAL CLOSE ENABLED
PLT06R PB6_PUL AND PLT06
PLT07S PB7_PUL AND NOT PLT07 # RECLOSE ENABLED
PLT07R PB7_PUL AND PLT07
NOTE: See corresponding command
descriptions SET L on page P.15.47
and SHO L on page P.15.51 to set or
show the free-form Protection
SEL
OGIC control equations.
NOTE: See corresponding command
descriptions SET A on page P.15.46
and SHO A on page P.15.50 to set or
show the Automation settings.
NOTE: The -0 version of the relay
has a capacity of 100 lines of
automation free-form SEL
OGIC control
equations in one automation setting
block.
