P.15.32
SEL-411L Relay Protection Manual Date Code 20151029
ASCII Command Reference
Description of Commands
The region option is the database region name shown in the simple MAP 1
command response. The region map consists of columns for data item labels,
database address, and data type.
If you specify the BL option and the region contains items with bit labels, the
relay lists these bit labels in MSB (most significant bit) to LSB (least
significant bit) order. Examples of database bit label names are Z1P,
25W1BK2, and ASV256.
METER
The METER command displays reports about quantities the relay measures
in the power system (voltages, currents, frequency, remote analogs, and so on)
and internal relay operating quantities (math variables and synchronism-check
values).
LINE, BK1, and BK2 command options generally measure feeder lines
parameters and circuit breaker currents, depending on relay configuration.
MET
Use the MET command to view fundamental metering quantities. The relay
filters harmonics and subharmonics to present only measured quantities at the
power system fundamental operating frequency.
The MET command without options defaults to the LINE fundamental
metering data. Specify Circuit Breaker 1 and Circuit Breaker 2 by using the
BK1 and BK2 command options, respectively.
Some situations require that you repeatedly monitor the power system for a
brief period; specify a number after any MET command to automatically
repeat the command.
Table 15.82 MAP 1 Region Command
Command Description Access Level
MAP 1 region List the data labels, database address, and data
type.
1, B, P, A, O, 2
MAP 1 region BL List the data labels, database address, and data
type; list the Bit Labels, if assigned.
1, B, P, A, O, 2
Ta b l e 1 5. 8 3 M E T C o m m a n d
Command
a
a
Parameter n is 1 or 2 to indicate Circuit Breaker 1 or Circuit Breaker 2.
Description Access Level
MET Display Line fundamental metering data. 1, B, P, A, O, 2
MET k Display Line fundamental metering data
successively for k times.
1, B, P, A, O, 2
MET BKn Display Circuit Breaker n fundamental
metering data.
1, B, P, A, O, 2
MET BKn k Display Circuit Breaker n fundamental
metering data successively for k times.
1, B, P, A, O, 2
