P.15.51
Date Code 20151029 Protection Manual SEL-411L Relay
ASCII Command Reference
Description of Commands
SHO F
Use the SHO F command to show the relay front-panel settings. There is only
one instance for the front-panel settings. See Section 7: Front-Panel
Operations for information on front-panel settings.
SHO G
Use the SHO G command to show the Global class settings. There is only one
instance for the Global class.
SHO L
Use the SHO L command to show the Protection SELOGIC control equations.
See Section 14: SEL
OGIC Control Equation Programming for more
information on SEL
OGIC control equations.
SHO M
Use the SHO M command to show the circuit breaker monitor settings. There
is only one instance for the Breaker Monitor class. See Section 9: Monitoring
and Metering for information on the circuit breaker monitor.
Ta b l e 1 5.1 3 1 SH O D C o m m a n d
Command Description Access Level
SHO D Show the DNP3 remapping settings for
instance 1.
P, A, O, 2
SHO D label Show the DNP3 remapping settings, beginning
at setting label for instance 1.
P, A, O, 2
SHO D instance Show the DNP3 remapping settings for
instance.
P, A, O, 2
Ta b l e 1 5.1 32 S H O F Co m m an d
Command Description Access Level
SHO F Show the front-panel relay settings, beginning
at the first setting in this class.
1, B, P, A, O, 2
SHO F label Show the front-panel relay settings, beginning
at the settings label label.
1, B, P, A, O, 2
Ta b l e 1 5.1 33 SH O G Co mm a nd
Command Description Access Level
SHO G Show the Global relay settings, beginning at
the first setting in this class.
1, B, P, A, O, 2
SHO G label Show the Global relay settings, beginning at
the settings label label.
1, B, P, A, O, 2
Ta b l e 1 5.1 3 4 S H O L Co m m an d
Command
a
a
Parameter n is 1–6 for Group 1–6.
Description Access Level
SHO L Show the Protection SELOGIC control equation
relay settings for the active group.
1, B, P, A, O, 2
SHO L n Show the Protection SEL
OGIC control equation
relay settings for Instance n, which is Group n.
1, B, P, A, O, 2
