P.10.16
SEL-411L Relay Protection Manual Date Code 20151029
Basic Relay Operations
Making Simple Settings Changes
When you exit settings entry from the SET commands, the relay responds,
Save settings (Y,N) ?. If you answer Y <Enter>, the relay writes the new
settings to nonvolatile storage. If you answer N <Enter>, the relay discards
any settings changes you have made.
Making Settings Changes: Initial Global Settings
You must configure the relay for specific conditions found in the power
system where you are connecting the relay. In particular, you must set the
nominal frequency and phase rotation.
The procedure in the following steps assumes that you have successfully
established communication with the relay; see Making an EIA-232 Serial Port
Connection for a step-by-step procedure. In addition, you must be familiar
with relay access levels and passwords. See Changing the Default Passwords:
Ter minal to change the default access level passwords.
This example jumps to a Global setting that is not at the beginning of the
Global settings list. Thus, you enter SET G, the setting name, and <Enter>.
To start at the beginning of the Global settings, simply type SET G <Enter>
without a settings name.
Step 1. Prepare to control the relay at Access Level 2.
a. Using a communications terminal, type ACC <Enter>.
b. Type the Access Level 1 password and press <Enter>.
You will see the Access Level 2 => prompt.
c. Type the 2AC <Enter> command.
d. Type the correct password to go to Access Level 2.
You will see the Access Level 2 =>> prompt.
Step 2. Type SET G DATE_F <Enter> (this sets the date format using
the DATE_F setting, which has options of MDY, YMD, or DMY).
The relay responds with a terminal screen display similar to the
beginning of Figure 10.11.
Table 10.5 Actions at Settings Prompts
Action Relay Response
<Enter> Accept setting and move to the next setting; if at the last setting, exit settings.
[value]
<Enter> Enter the given value and move to the next setting if valid; if at the last
setting, exit settings.
^ <Enter> Move to the previous setting; if at the top of settings, stay at the present
setting.
< <Enter> Move to the top of the previous settings category; if at the top of
settings, stay at the present setting.
> <Enter> Move to the top of the next settings category; if in the last category,
exit settings.
END <Enter> Go to the end of the present settings session. Prepare to exit settings
via the
Save settings (Y,N) ? prompt.
<Ctrl+X> Abort the editing session without saving changes.
