P.5.4
SEL-411L Relay Protection Manual Date Code 20151029
Settings
Global Settings
Global Settings
NOTE: See corresponding command
descriptions SET G on page P.15.47
and SHO G on page P.15.51 to set or
show the Global settings.
TLED_19 79_CYC
TLED_20 25_SYNC
TLED_21 50PICUP
TLED_22 51PICUP
TLED_23 LOPTN
TLED_24 IRIGLCK
Table 5.2 Default Alias Settings (Sheet 2 of 2)
Label Default Value
Table 5.3 Global Settings Categories
Settings Reference
General Global Settings Table 5.4
Global Enables Table 5.5
Station DC1 Monitor (and Station DC2 Monitor) Table 5.6
Control Inputs (Global) Table 5.7
Interface Board #1 Control Inputs Table 5.8
Interface Board #2 Control Inputs Table 5.9
Settings Group Selection Table 5.10
Data Reset Control Table 5.11
Frequency Estimation Table 5.12
Time-Error Calculation Table 5.13
Current and Voltage Source Selection Table 5.14
Synchronized Phasor Measurement Table 5.15
Time and Date Measurement Table 5.16
Table 5.4 General Global Settings
Label Prompt Default Value
SID Station Identifier (40 characters) Station A
RID Relay Identifier (40 characters) Relay 1
NUMBK Number of Breakers in Scheme (1, 2) 1
BID1 Breaker 1 Identifier (40 characters) Breaker 1
BID2 Breaker 2 Identifier (40 characters) Breaker 2
NFREQ Nominal System Frequency (50, 60 Hz) 60
PHROT System Phase Rotation (ABC, ACB) ABC
FAULT Fault Condition Equation SEL
OGIC Equation) 50P1 or 51S01 or Z2P or
Z2G or Z3P or Z3G or
87LP or 87LQ or 87LG
