P.5.23
Date Code 20151029 Protection Manual SEL-411L Relay
Settings
Port Settings
Make Table 5.43 settings if Port setting PROTO := RTD.
Table 5.43 RTD Protocol Settings
Label Prompt Default Value
RTDNUM RTD Number of Inputs (0–12) 12
RTDnTY
a
a
Where n is the number of RTD inputs enabled in the RTDNUM setting.
RTD n Type (NA, PT100, NI100, NI120, CU10)
b
b
NA designates an input that is not connected to an RTD device.
PT100
Table 5.44 PMU Protocol Settings
Label Prompt Default Value
PMUMODE PMU Mode (CLIENTA, CLIENTB, SERVER) SERVER
RTCID
a
a
Setting hidden when PMUMODE := SERVER.
Remote PMU Hardware ID (1–65534) 1
Ta b l e 5. 4 5 87 L P o r t S e tt i n g s
Label Prompt Default Value
E87CH
a
Enable 87L Channel (N, 2SS, 2SD, 3SS, 3SM, 2E, 3E, 4E) N
E87PG
b
87L Port Address Location G = Group, P = Port (G, P) P
87PCH
c
87L Primary Serial Channel (1, 2) 1
87TADR
b,d
Relay Transmit Address (1–255) 1
87R1ADR
e,d
Channel 1 Receive Address (1–255) 2
87R2ADR
d,f
Channel 2 Receive Address (1–255) 3
87RXCE1
g
Channel 1 EIA-422 Receive Clock Edge (R, F) R
87TXCE1
g
Channel 1 EIA-422 Transmit Clock Edge (R, F) R
87RXCE2
g
Channel 2 EIA-422 Receive Clock Edge (R, F) R
87TXCE2
g
Channel 2 EIA-422 Transmit Clock Edge (R, F) R
87TIMC1
h
Channel 1 Timing Source (I = Internal, E = External) I
87TIMC2
i
Channel 2 Timing Source (I = Internal, E = External) I
ECH1OUT
j
Enable Channel 1 out of Service (SELOGIC Equation) NA
ECH2OUT
j
Enable Channel 2 out of Service (SELOGIC Equation) NA
87LTMAC
k
MAC Address For 87L Transmit (01-30-A7-xx-xx-xx) 01-30-A7-01-01-01
87LMAC1
k,l
MAC For 87L Remote 1 Receipt (01-30-A7-xx-xx-xx) 01-30-A7-01-01-02
87LMAC2
l,m
MAC For 87L Remote 2 Receipt (01-30-A7-xx-xx-xx) 01-30-A7-01-01-03
87LMAC3
l,n
MAC For 87L Remote 3 Receipt (01-30-A7-xx-xx-xx) 01-30-A7-01-01-04
87LVLAN
o
VLAN tag for 87L Ethernet (1–4094) 101
87LPRI
o
Ethernet Priority for 87L (0–7) 3
87ETHJT
o
Jitter in 87L Ethernet network (0.0–3.5 ms) 1
E87VT
p
Enable Virtual Terminal over 87L Serial Channel (Y, N) N
a
The settings range dependents on the hardware configuration (part number). There are five options:
1 serial communication card (no Ethernet): N, 2SS, 3SS
2 serial communication cards (no Ethernet): N, 2SS, 2SD, 3SS, 3SM
Ethernet (no serial): N, 2E, 3E, 4E
1 serial card and Ethernet: N, 2SS, 3SS, 2E, 3E, 4E
2 serial communication cards Ethernet: N, 2SS, 2SD, 3SS, 3SM, 2E, 3E, 4E
b
This setting is hidden if E87CH = 2E, 3E, 4E.
c
This setting is hidden with a value of 1 if E87CH = 3SM, 2E, 3E, 4E, or if the relay has a single serial card, located in Bay A (Channel 1). This
setting is hidden with a value of 2 if the relay has a single serial card, located in Bay B (Channel 2).
d
Be sure to set 87TADR, 87R1ADR and 87R2ADR to unique addresses (unless E87CH=2SD, in which case 87R1ADR and 87R2ADR are the same).
