P.15.19
Date Code 20151029 Protection Manual SEL-411L Relay
ASCII Command Reference
Description of Commands
DNAME X
The DNA X command produces the ASCII names of all relay digital I/O
(input/output) quantities reported in a Fast Meter message in Compressed
ASCII format.
DNP
The DNP command accesses the serial port DNP3 settings and is similar to
the SHOW D command. Type DNP <Enter> to show the relay serial port
DNP3 settings beginning at the first setting label. Issue the DNP command
with any parameter param to set the serial port DNP settings; the relay begins
at the first DNP3 setting.
ETHERNET
The ETH command displays the current Ethernet port (Port 5) configuration
and status.
ETH
Use the ETH command when troubleshooting Ethernet connections.
Figure 15.1 shows a sample ETH command response for a relay with four
copper Ethernet ports and Port 5 setting NETMODE = SWITCHED. Different
Ethernet configurations and different NETMODE settings result in slightly
different information being displayed. See Ethernet Network Operation
Settings on page C.1.5 for a description of the settings and operating modes
related to the Ethernet port.
==>>ETH <Enter>
Relay 1 Date: 11/04/2010 Time: 10:22:19.984
Station A Serial Number: 0000000000
MAC: 00-30-A7-01-E3-0A
IP ADDRESS: 10.201.5.27/16
DEFAULT GATEWAY: 10.201.0.1
NETMODE: SWITCHED
PRIMARY 87L PORT: 5A
ACTIVE 87L PORT: 5A
Ta b l e 1 5. 49 D N A Co m m an d
Command Description Access Level
DNA X Display ASCII names of all
relay digital I/O.
0, 1, B, P, A, O, 2
Ta b l e 1 5. 5 0 D NP Co m ma nd
Command Description Access Level
DNP Show the serial port DNP3 settings (same as
SHOW D).
1, B, P, A, P, O, 2
DNP VIEW Show the serial port DNP3 settings (same as
SHOW D).
1, B, P, A, P, O, 2
DNP param Set the serial port DNP3 settings (same as SET
D); begin at the first DNP3 setting.
P, A, O, 2
Ta b l e 1 5. 5 1 E T H C o m m a n d
Command Description Access Level
ETH Displays information about Ethernet port(s) 1, B, P, A, O, 2
