P.15.22
SEL-411L Relay Protection Manual Date Code 20151029
ASCII Command Reference
Description of Commands
EVE Lyyy
Command EVE Lyyy returns a specified length event report, where Lyyy
indicates a length of yyy cycles. You can specify yyy from 1 cycle up to a value
including and exceeding the event report total cycle length. If yyy is longer
than the total length, the relay returns the full duration event report. The Lyyy
option overrides the C option.
EVE NEXT
EVE NEXT returns the oldest unacknowledged event report on the present
communications port.
EVE NSET
The EVE NSET command returns the event report with no relay settings.
EVE NSUM
The EVE NSUM returns the event report with no event summary.
Table 15.59 EVE Lyyy Command
Command
a
a
Parameter n indicates event order or serial number; see EVE.
Description Access Level
EVE Lyyy Return yyy cycles of the most recent event
report (including settings) with 4
-samples/
cycle data.
1, B, P, A, O, 2
EVE n Lyyy Return yyy cycles of a particular n event report
with 4
-samples/cycle data.
1, B, P, A, O, 2
Ta b l e 1 5. 6 0 EV E N Co m ma n d
Command Description Access Level
EVE N Return the oldest unacknowledged event report
with 4
-samples/cycle data.
1, B, P, A, O, 2
Table 15.61 EVE NSET Command
Command
a
a
Parameter n indicates event order or serial number; see EVE.
Description Access Level
EVE NSET Return the most recent event report without
settings at full length with 4-samples/cycle
data.
1, B, P, A, O, 2
EVE n NSET Return a particular n event report without
settings at full length with 4
-samples/cycle
data.
1, B, P, A, O, 2
Ta b l e 1 5. 6 2 EV E N S U M C o m m a n d
Command
a
a
Parameter n indicates event order or serial number.
Description Access Level
EVE NSUM Return the most recent event report without the
event summary at full length with 4-samples/
cycle data.
1, B, P, A, O, 2
EVE n NSUM Return a particular n event report without the
event summary at full length with 4-samples/
cycle data.
1, B, P, A, O, 2
