P.15.48
SEL-411L Relay Protection Manual Date Code 20151029
ASCII Command Reference
Description of Commands
The relay presents text-edit mode entry format for the free-form SELOGIC
control equations you program in the Protection SEL
OGIC control equation
settings area.
SET M
Use the SET M command to set the circuit breaker monitor settings. There is
only one instance for the Breaker Monitor class. See Section 9: Monitoring
and Metering for information on the circuit breaker monitor.
SET N
Use the SET N command to leave a message in the relay.
SET O
Use the SET O command to set the Output SELOGIC control equations.
SET P
Use the SET P command to configure the relay communications ports; each
port is a settings instance. The relay communications ports include serial ports
at PORT F, PORT 1, PORT 2, and PORT 3. PORT 5 is the Ethernet card port into
which the optional Ethernet card may be installed.
Table 15.121 SET M Command
Command Description Access Level
SET M Set the Breaker Monitor relay settings,
beginning at the first setting in this class.
P, 2
SET M label Set the Breaker Monitor relay settings,
beginning at the settings label label.
P, 2
Table 15.122 SET N Command
Command Description Access Level
SET N Enter text using the text-edit format. P, A, O, 2
Ta b l e 1 5.1 23 S E T O Co m m an d
Command Description Access Level
SET O Set the Output SELOGIC control equation relay
settings, beginning at OUT101.
O, 2
SET O label Set the Output SEL
OGIC control equation relay
settings, beginning at the output label label.
O, 2
Table 15.124 SET P Command
Command
a
a
Parameter p = 1–3, F, or 5, corresponding to PORT 1–PORT 3, PORT F, or PORT 5.
Description Access Level
SET P Set the port presently in use, beginning at the first
setting for this port.
P, A, O, 2
SET P label Set the port presently in use, beginning at the
settings label label.
P, A, O, 2
SET P p Set the communications Port relay settings for
Port p, beginning at the first setting for this port.
P, A, O, 2
SET P p label Set the communications Port relay settings for
Port p, beginning at the settings label label.
P, A, O, 2
