P.5.20
SEL-411L Relay Protection Manual Date Code 20151029
Settings
Port Settings
Table 5.40 DNP3 Serial Protocol Settings
Label Prompt Default Value
DNPADR DNP3 Address (0–65519) 0
DNPID DNP3 ID for Object 0, Var 246 (20 characters) “RELAY1-DNP”
DNPMAP DNP3 Session Map (1–5) 1
ECLASSB Class for Binary Event Data (OFF, 1–3) 1
ECLASSC Class for Counter Event Data (OFF, 1–3) OFF
ECLASSA Class for Analog Event Data (OFF, 1–3) 2
ECLASSV Class for Virtual Terminal Data (OFF, 1–3) OFF
TIMERQ Time-Set Request Interval (I, M, 1–32767 minutes) I
DECPLA Currents Scaling (0–3 decimal places) 1
DECPLV Voltages Scaling (0–3 decimal places) 1
DECPLM Miscellaneous Data Scaling (0–3 decimal places) 1
STIMEO Select/Operate Time-Out (0.00–60.00 seconds) 1
DRETRY Data Link Retries (OFF, 1–15) OFF
DTIMEO
a
a
Hidden if DRETRY = OFF.
Data Link Time-Out (0.00–30.00 seconds) 1
MINDLY Minimum Delay from DCD to TX (0.00–1.00 seconds) 0.05
MAXDLY Maximum Delay from DCD to TX (0.00–1.00 seconds) 0.10
PREDLY Settle Time-RTS On to TX (OFF, 0.00–30.00 seconds) 0.00
PSTDLY Settle Time-TX to RTS Off (0.00–30.00 seconds) 0.00
DNPCL Enable Control Operations (Y, N) N
AIVAR Default Variation for Analog Inputs (1–6) 2
ANADBA Analog Reporting Deadband for Currents (0–32767) 100
ANADBV Analog Reporting Deadband for Voltages (0–32767) 100
ANADBM Analog Reporting Deadband (0–32767) 100
ETIMEO Event Message Confirm Time-Out (1–50 seconds) 2
UNSOL Enable Unsolicited Reporting (Y, N) N
PUNSOL
b
b
Hidden if UNSOL = N.
Enable Unsolicited Reporting at Power-Up (Y, N) N
REPADR DNP Address to Report to (0–65519) 1
NUMEVE Number of Events to Transmit On (1–200) 10
AGEEVE Age of Oldest Event to Transmit On (0–99999 s) 2
URETRY Unsolicited Message Max Retry Attempts (2–10) 3
UTIMEO Unsolicited Message Offline Time-Out (OFF, 1–5000 sec) 60
MODEM Modem Connected to Port (Y, N) N
MSTR Modem Startup String (30 characters max.) “E0X0&D0S0=4”
PH_NUM1 Phone Number for Dial-Out (30 characters max.) “”
PH_NUM2 Backup Phone Number for Dial-Out (30 characters max.) “”
RETRY1 Retry Attempts for Phone 1 Dial-Out (1–20) 5
RETRY2 Retry Attempts for Phone 2 Dial-Out (1–20) 5
MDTIME Time to Attempt Dial (5–300 seconds) 60
MDRET Time Between Dial-Out Attempts (5–3600 seconds) 120
