Sel 411L - Table 2.6 I;O Board Jumpers

P.2.23
Date Code 20151029 Protection Manual SEL-411L Relay
Installation
Jumpers
OUT201, OUT202, etc. A 5U chassis has a 200-addresses slot and a
300-addresses slot. A 6U chassis has a 200-addresses slot, a 300-addresses
slot, and a 400-addresses slot.
The drawout tray on which each I/O board is mounted is keyed. See Installing
Optional I/O Interface Boards for information on the key positions for the
200-addresses slot trays, 300-addresses slot trays, and 400-addresses slot
trays.
Changing I/O Interface Board Jumpers
Change the I/O interface board jumpers only when you move the slot position
of an I/O board. You must remove the I/O interface boards to access the
jumpers. Perform the following steps to change jumpers on an I/O interface
board:
Step 1. Follow your company standard to remove the relay from
service.
Step 2. Disconnect power from the relay.
Step 3. Retain the GND connection, if possible, and ground the
equipment to an ESD mat.
Step 4. Remove the communications cable connected to the front-panel
serial port, if applicable.
Step 5. Loosen the four front-panel screws (they remain attached to the
front panel), and remove the relay front panel.
Step 6. Remove the 34-pin ribbon cable from the front panel by
pushing the extraction ears away from the connector.
Step 7. Disconnect the power, the interface board, and the analog input
board cables from the main board.
Step 8. Pull out the drawout assembly containing the I/O interface
board.
Step 9. Locate the jumper you want to change.
The I/O interface board jumpers are located near the front of
each I/O board, and near the interface board connector, as
shown for each type of interface board in
Figure 2.17–Figure 2.20.
Step 10. Install or remove the jumper as needed (see Table 2.6 for
jumper position descriptions).
Step 11. Reinstall the interface board, and reconnect the power, the
interface board, and the analog input board cables.
Step 12. Reconnect the cable removed in Step 6 and reinstall the relay
front-panel cover.
Ta b l e 2 . 6 I/O B o a r d J u m p e r s
I/O Board
Control
Address
JMP1A/
JMP49A
a
a
INTC and INTD I/O Interface Board jumper numbering.
JMP1B/
JMP49B
a
JMP2A/
JMP50A
a
JMP2B/
JMP50B
a
2XX OFF OFF OFF OFF
3XX ON OFF ON OFF
4XX OFF ON OFF ON
DANGER
Disconnect or de-energize all external
connections before opening this
device. Contact with hazardous
voltages and currents inside this
device can cause electrical shock
resulting in injury or death.
WARNING
Have only qualified personnel service
this equipment. If you are not
qualified to service this equipment,
you can injure yourself or others, or
cause equipment damage.
CAUTION
Equipment components are sensitive
to electrostatic discharge (ESD).
Undetectable permanent damage can
result if you do not use proper ESD
procedures. Ground yourself, your
work surface, and this equipment
before removing any cover from this
equipment. If your facility is not
equipped to work with these
components, contact SEL about
returning this device and related SEL
equipment for service.
