Sel 411L - Figure 8.5 COMTRADE.CFG Configuration File Data

P.8.10
SEL-411L Relay Protection Manual Date Code 20151029
Oscillography, Events, and SER
Oscillography
*Digital points are all the Relay Word bits set in ERDG as well as the Relay Word bits that are always included in the event
report.
Figure 8.5 COMTRADE .CFG Configuration File Data
The configuration file has the following format:
➤ Station name, device identification, COMTRADE standard
year
➤ Number and type of channels
➤ Channel name units and conversion factors
➤ Line frequency
➤ Sample rate and number of samples
➤ Date and time of first data point
➤ Date and time of trigger point
➤ Data file type
➤ Time stamp multiplication factor
.DAT File
The .DAT file follows the COMTRADE binary standard. The format of the
binary data files is sample number, time stamp, data value for each analog
channel, and grouped status channel data for each sample in the file. There are
no data separators in the binary file, and the file contains no carriage
return/line feed characters. The sequential position of the data in the binary
Station A,FID=SEL-411L-1-R100-V0-Z001001-D20110311,1999
398,14A,384D
1,IAW,A,,A,0.324059,0,0,-32767,32767,200.0,1,P
2,IBW,B,,A,0.324059,0,0,-32767,32767,200.0,1,P
3,ICW,C,,A,0.324059,0,0,-32767,32767,200.0,1,P
4,IAX,A,,A,0.324059,0,0,-32767,32767,200.0,1,P
5,IBX,B,,A,0.324059,0,0,-32767,32767,200.0,1,P
6,ICX,C,,A,0.324059,0,0,-32767,32767,200.0,1,P
7,VAY,A,,kV,0.032406,0,0,-32767,32767,2000.0,1,P
8,VBY,B,,kV,0.032406,0,0,-32767,32767,2000.0,1,P
9,VCY,C,,kV,0.032406,0,0,-32767,32767,2000.0,1,P
10,VAZ,A,,kV,0.032406,0,0,-32767,32767,2000.0,1,P
11,VBZ,B,,kV,0.032406,0,0,-32767,32767,2000.0,1,P
12,VCZ,C,,kV,0.032406,0,0,-32767,32767,2000.0,1,P
13,VDC1,,,V,0.011178,-0.000000,0,-32767,32767,1,1,P
14,VDC2,,,V,0.011178,-0.000000,0,-32767,32767,1,1,P
1,87USAFE,,,0
2,UNUSED2,,,0
3,UNUSED3,,,0
4,UNUSED4,,,0
5,OC1,,,0
6,CC1,,,0
7,OC2,,,0
8,CC2,,,0
9,87LA,,,0
10,87LB,,,0
11,87LC,,,0
12,87LQ,,,0
13,87LG,,,0
14,87FLSOK,,,0
15,87DTTRX,,,0
.
.
.
382,PCT06Q,,,0
383,PCT07Q,,,0
384,PCT08Q,,,0
60
1
2000,1000
17/03/2011,08:36:38.697687
17/03/2011,08:36:38.799850
BINARY
1
Relay Information (1999 = COMTRADE Standard)
398 = sum of analogs and digitals
14 Analog Channels
384 Digital Points
Nominal System Frequency (NFREQ Setting)
2000 = Sample Rate (SRATE setting)
14A = total number of analog channels
384D = total number of digital points*
1000 = Length of the Report x Sample Rate (LER x SRATE)
Time Stamp of the First Data Point
Time Stamp of the Trigger Point
