Sel 411L - Figure 8.17 Sample Compressed ASCII History Report

P.8.30
SEL-411L Relay Protection Manual Date Code 20151029
Oscillography, Events, and SER
Event Reports, Event Summaries, and Event Histories
You can use ACSELERATOR QuickSet to retrieve the relay event history. Use
the Analysis > View Event History menu to view the Event History dialog
box. See
ACSELERATOR QuickSet Event Analysis on page P.6.15 for
information and examples.
Figure 8.17 Sample Compressed ASCII History Report
CHISTORY
The relay outputs a Compressed ASCII history report for SCADA and other
automation applications. Issue the CHI command to view the Compressed
ASCII history report. A sample of the report appears in Figure 8.17; this is a
comma-delimited ASCII file. The relay appends a four-digit hex checksum at
the end of each history in the Compressed ASCII history report.
Items included in the Compressed ASCII history report are similar to those
included in the history report, although the relay reports the items in a special
order. For the purpose of improving products and services, SEL sometimes
changes the items and item order.
History File Download
You can also download the history report file from the relay. Use a terminal
emulation program with file transfer capability. At an Access Level 1 prompt
or higher type FILE READ REPORTS HISTORY.TXT <Enter>. Start the
HIS CA Clear event data for all ports.
HIS RA Clear event data for all ports.
a
Use the same date format as Global setting DATE_F.
Table 8.9 HIS Command (Sheet 2 of 2)
Command Description
"RID","SID","FID","03e2"
"Relay 1","Station A","FIDSEL-411L-R101-V0-Z001001-D20010315","0f0c"
"EVENT_NUM","EVENT","LOCATION","FREQ","NFREQ","SAM/CYC_A","SAMCYC_D","NUM_OF_CYC","SER_NUM",
"PRIM_VAL","CTR_IA","CTR_IB","CTR_IC","CTR_IG","PTR_VA","PTR_VB","PTR_VC","PTR_VS1","PTR_VS2",
"CTRW","CTRX","PTRY","PTRZ","ERAQ01","ERAQ02","ERAQ03","ERAQ04","ERAQ05","ERAQ06","ERAQ07",
"ERAQ08","ERAQ09","ERAQ10","ERAQ11","ERAQ12","ERAQ13","ERAQ14","ERAQ15","ERAQ16","ERAQ17",
"ERAQ18","ERAQ19","ERAQ20","GROUP","BREAKER1","HOUR_T1","MIN_T1","SEC_T1","MSEC_T1","HOUR_C1",
"MIN_C1","SEC_C1","MSEC_C1","BREAKER2","HOUR_T2","MIN_T2","SEC_T2","MSEC_T2","HOUR_C2","MIN_C2",
"SEC_C2","MSEC_C2","T_LED1","T_LED2","TARGETS","MB_TRIGGER","MB_TRIP","IA_PF","IA_DEG_PF",
"IB_PF","IB_DEG_PF","IC_PF","IC_DEG_PF","IG_PF","IG_DEG_PF","3I2_PF","3I2_DEG_PF","I1_PF",
"I1_DEG_PF","VA_PF","VA_DEG_PF","VB_PF","VB_DEG_PF","VC_PF","VC_DEG_PF","VS1_PF","VS1_DEG_PF",
"VS2_PF","VS2_DEG_PF","V1MEM_PF","V1MEM_DEG_PF","V0_PF","V0_DEG_PF","V2_PF","V2_DEG_PF","V1_PF",
"V1_DEG_PF","IA","IA_DEG","IB","IB_DEG","IC","IC_DEG","IG","IG_DEG","3I2","3I2_DEG","I1","I1_DEG",
"VA","VA_DEG","VB","VB_DEG","VC","VC_DEG","VS1","VS1_DEG","VS2","VS2_DEG","V1MEM","V1MEM_DEG","V0",
"V0_DEG","V2","V2_DEG","V1","V1_DEG","1A01"
10007,3,15,2001,23,30,49,26,900,"BCG
T",48.17,"OTHER",0,0,60.01,1,"OPEN",23,30,49,26,,,,,"OPEN",23,30,49,26,,,,,28872,"
INST TIME ZONE_1 B_PHASE C_PHASE GROUND
bk1rs","0000000000","0000000000",276,22.05,262,-
91.71,246,138.23,65,5.11,17,178.47,261,22.93,365,0.00,365,-
119.87,364,120.30,361,-88.78,362,151.39,365,-0.01,1,-117.90,0,-
43.94,365,0.14,217,-16.99,8892,167.27,8727,24.82,5586,95.60,11403,94.44,5789,-
83.19,361,0.07,219,-129.89,214,126.73,361,-
88.92,362,151.24,321,0.75,31,2.67,67,2.55,263,-0.87,"637E"
00006,3,15,2001,7,15,0,635,900,"ABC
T",22.82,"OTHER",0,1,59.98,1,"OPEN",7,15,0,635,,,,,"OPEN",7,15,0,635,,,,,57480,"IN
ST ZONE_1 A_PHASE
bk1rs","0000000000","0000000000",9,125.27,9,128.10,7,96.08,24,118.43,5,109.90,1,
-120.66,0,79.68,0,73.83,0,106.76,0,134.13,0,178.99,0,99.44,0,87.50,0,-
80.58,0,73.48,8203,-91.24,6617,148.12,7485,39.60,70,113.90,1757,-118.74,7404,-
87.80,32,0.00,40,-118.11,38,110.17,0,88.59,1,-79.09,26,-7.83,0,-
165.97,6,159.23,36,-2.68,"5A30"
00005,3,15,2001,6,43,53,428,900,"TRIG",$$$$.$$,"OTHER",0,0,60.00,1,"OPEN",,,,,,,,
,"NA",,,,,,,,,0,"","0000000000","0000000000",0,144.30,1,106.07,1,60.80,1,94.40,0
,176.31,0,-112.74,0,125.20,0,-67.34,0,-150.44,0,-21.16,0,80.35,0,34.89,0,-170.50
,0,138.88,0,94.55,1,0.00,0,41.08,1,-16.92,2,-1.92,2,19.32,0,-26.30,0,-174.55,0,-
58.17,0,-64.16,0,-70.49,0,131.85,0,34.89,0,-110.51,0,121.49,0,177.31,"49C7"
Report Header
Report Labels
Report Data
