Protection Functions
Over/Undervoltage Elements
27TCk Undervoltage Element Torque Control
The 27TCk (k = 1–6) undervoltage element torque control uses a SELOGIC
control equation to provide torque control of the undervoltage elements. All
undervoltage elements are blocked from operation when the 27TCk input
evaluates to a zero. The default setting of 1 allows the undervoltage elements
to always operate.
27PkD1 Undervoltage Element Level 1 Delay
When the system voltage falls below the undervoltage setting value, the
undervoltage timer starts timing. Set the delay (in cycles) for which the timer
must run before the 27PkD1 (k = 1–6) setting asserts the output.
E59 Enable Overvoltage Elements
Use the E59 setting to enable the number of overvoltage elements you want to
use in the relay. Each overvoltage element provides two pickup setting levels.
59On Overvoltage Element Operating Quantity
Select the operating quantity 590n (n = 1–6) you want for each voltage
terminal from Table 3.113.
Setting Prompt Range Default Category
27TCk U/V Element k Torque Control
(SEL
OGIC Eqn.)
SV (SEL
OGIC
variables)
1Group
Setting Prompt Range Default Category
27PkD1 U/V Element k Level 1 Delay
(0.00–16000 cyc.)
0.00–16000 10.00 Group
Setting Prompt Range Default Category
E59 Enable Overvoltage Elements (N, 1–6) N, 1–6 N Group
Table 3.113 Overvoltage Operating Quantity List
Label Description
VAFIM A-phase filtered instantaneous phase voltage magnitude
VBFIM B-phase filtered instantaneous phase voltage magnitude
VCFIM C-phase filtered instantaneous phase voltage magnitude
V1FIM Positive-sequence instantaneous voltage magnitude
3V2FIM Negative-sequence instantaneous voltage magnitude
3V0FIM Zero-sequence instantaneous voltage magnitude
VNMAXF Instantaneous filtered maximum phase-to-neutral voltage magnitude
VNMINF Instantaneous filtered minimum phase-to-neutral voltage magnitude
VPMAXF Instantaneous filtered maximum phase-to-phase voltage magnitude
VPMINF Instantaneous filtered minimum phase-to-phase voltage magnitude
