Sel 411L - Table 15.114 SET Command Overview; Table 15.115 SET a Command; Table 15.116 SET B Command

P.15.46
SEL-411L Relay Protection Manual Date Code 20151029
ASCII Command Reference
Description of Commands
SET
The SET command with no options or parameters accesses the relay settings
Group class and the instance corresponding to the active group. To set a
different instance, specify the instance number (1–6).
The relay validates your settings entries as you enter each setting. At the end
of a settings instance session, the relay responds with a readback of all the
settings in the settings instance; then prompts,
Save settings (Y,N)? If you
answer Y <Enter>, the relay pulses the Relay Word bit SALARM, and
responds,
Saving Settings, Please Wait........... The relay saves the
new settings, then responds,
Settings Saved. If you answer N <Enter> to the
save settings prompt, the relay responds,
Settings aborted.
SET A
Use the SET A command to set the Automation SELOGIC control equations.
The relay presents text-edit mode entry format for the free-form SEL
OGIC
control equations you program in the Automation SEL
OGIC control equations
settings area. See Text-Edit Mode Line Editing on page P.10.18 for
information on settings text-edit mode.
SET B
Use the SET B command to configure the capacitor bank bay for display on
the control from the front panel. Choose the appropriate busbar and capacitor
representations to configure the one-line diagram applicable to your
application.
Table 15.114 SET Command Overview
Command
a
a
Parameter n = 1–6, representing Group 1–6.
Description Access Level
SET Set the Group relay settings, beginning at the first
setting in the active group.
P, 2
SET n Set the Group n relay settings, beginning at the first
setting n each instance.
P, 2
SET label Set the Group relay settings, beginning at the active
group setting label label.
P, 2
SET n label Set the Group n relay settings, beginning at setting label
label.
P, 2
Table 15.115 SET A Command
Command
a
a
Parameter n = 1–10 for Block 1–10.
Description Access Level
SET A Set the Automation SELOGIC control equation
relay settings in Block 1.
A, 2
SET A n Set the Automation SEL
OGIC control equation
relay settings in Block n.
A, 2
Ta b l e 1 5.1 1 6 S E T B Co m m an d
Command Description Access Level
SET B Bay control settings, beginning at the first setting in this
class
P, A, O, 2
SET B label Bay control settings, beginning at the setting label. P, A, O, 2
