P.5.7
Date Code 20151029 Protection Manual SEL-411L Relay
Settings
Global Settings
Make Table 5.12 settings when Global enable setting EGADVS := Y.
See Current and Voltage Source Selection on page P.3.106 for more
information on Table 5.14 settings.
Make Table 5.15 settings when Global enable setting EPMU := Y.
Table 5.12 Frequency Estimation
Label Prompt
Default
Value
EAFSRC Alternate Frequency Source (SELOGIC Equation) NA
VF01 Local Frequency Source 1 (ZERO, VAY, VBY, VCY, VAZ, VBZ,
VCZ)
VAY
VF02 Local Frequency Source 2 (ZERO, VAY, VBY, VCY, VAZ, VBZ,
VCZ)
VBY
VF03 Local Frequency Source 3 (ZERO, VAY, VBY, VCY, VAZ, VBZ,
VCZ)
VCY
VF11 Alternate Frequency Source 1 (ZERO, VAY, VBY, VCY, VAZ,
VBZ, VCZ)
ZERO
VF12 Alternate Frequency Source 2 (ZERO, VAY, VBY, VCY, VAZ,
VBZ, VCZ)
ZERO
VF13 Alternate Frequency Source 3 (ZERO, VAY, VBY, VCY, VAZ,
VBZ, VCZ)
ZERO
Table 5.13 Time-Error Calculation
Label Prompt Default Value
STALLTE Stall Time-Error Calculation (SELOGIC Equation) NA
LOADTE Load TECORR Factor (SEL
OGIC Equation) NA
Table 5.14 Current and Voltage Source Selection
Label Prompt Default Value
ESS Current and Voltage Source Selection (Y, N, 1, 2, 3, 4) N
LINEI Line Current Source (IW, COMB) IW
ALINEI Alternate Line Current Source (IX, NA) NA
ALTI Alternate Current Source (SEL
OGIC Equation) NA
BK1I Breaker 1 Current Source (IW, IX, NA) IW
BK2I Breaker 2 Current Source (IX, COMB, NA) NA
IPOL Polar. Current (IAX, IBX, ICX, NA) NA
ALINEV Alternate Line Voltage Source (VZ, NA) NA
ALTV Alternate Voltage Source (SEL
OGIC Equation) NA
Table 5.15 Synchronized Phasor Measurement (Sheet 1 of 2)
Label Prompt
Default
Value
MFRMT Message Format (C37.118, FM) C37.118
MRATE
a
Messages per Second
(1, 2, 5, 10, 25, 50) when NFREQ = 50
(1, 2, 4, 5, 10, 12, 15, 20, 30, 60) when NFREQ = 60
2
PMAPP PMU Application (F = Fast Response, N = Narrow
Bandwidth, 1 = Extra Narrow
b
)
N
