P.5.10
SEL-411L Relay Protection Manual Date Code 20151029
Settings
Notes Settings
Notes Settings
Avoid losing important information about the relay. Use the Notes settings
like a text pad to leave notes about the relay in Notes area of the relay. Notes
SEL
OGIC control equations are in a single block of 100 lines (see Section 14:
SEL
OGIC Control Equation Programming). The relay does not contain any
automation SEL
OGIC settings in the factory default settings.
Output Settings
Make Table 5.20 settings if interface board #1 is present.
Make Table 5.21 settings if interface board #2 is present.
NOTE: See corresponding SET N
command descriptions (SET N on
page P.15.48) and SHO N command
descriptions (SHO N on page P.15.52)
to set or show the Automation
settings.
Table 5.19 Output Settings Categories
Settings Reference
Interface Board #1 Table 5.20
Interface Board #2 Table 5.21
Ethernet Card Outputs Table 5.22
M
IRRORED BITS Transmit Equations Table 5.23
87L Communication Bits Transmit Equations Table 5.24
Ta b l e 5. 2 0 I n te r fa ce B o a r d # 1
Label Prompt Default Value
OUT201 (3PT OR TPA1) AND NOT PLT04
#THREE POLE TRIP
OUT202 (3PT OR TPA1) AND NOT PLT04
#THREE POLE TRIP
OUT203 BK1CL AND NOT PLT04
#BREAKER CLOSE COMMAND
OUT204 KEY AND PLT02 AND NOT
PLT04 #KEY TX
OUT205 NA
OUT206 87TOUT
OUT207 PLT04 #RELAY TEST MODE
OUT208 NOT (SALARM OR HALARM)
OUT209–
OUT210
NA
Table 5.21 Interface Board #2
Label Prompt Default Value
OUT301 NA
•
•
•
•
•
•
•
•
•
OUT316 NA
