P.5.26
SEL-411L Relay Protection Manual Date Code 20151029
Settings
Bay Settings
Make Table 5.52 settings if preceding setting DNPBOD := N.
Make Table 5.53 settings if preceding setting DNPCOD := N.
Make Table 5.54 settings if preceding setting DNPAID := N.
Make Table 5.55 settings if preceding setting DNPAOD := N.
The fault location minimum and maximum settings determine what fault data are
sent to a DNP3 master. This affects all DNP3 sessions using the current DNP3 map.
Bay Settings
Table 5.52 Binary Output Map
Label Prompt Default Value
BO_n Binary Output label, label pair, or NOOP. See Table 4.10.
Table 5.53 Counter Map
a
a
Parameter x is A, V, M representing currents, voltages, and miscellaneous, respectively.
Label Prompt Default Value
CO_n Counter Label or 0. See Table 4.10.
CO_DBDn Deadband (1–32767) (ANADBx port
setting)
Table 5.54 Analog Input Map
a
a
Parameter x is A, V, M representing currents, voltages, and miscellaneous, respectively.
Label Prompt Default Value
AI_n Analog Input label or 0. See Table 4.10.
AI_SCAn Scale Factor (0.001–1000.000)
AI_DBDn Deadband (1–32767)
Table 5.55 Analog Output Map
Label Prompt Default Value
AO_n Analog Output label map or NOOP. See Table 4.10.
Table 5.56 Minimum and Maximum Fault Location
Label Prompt Default Value
MINDIST Min Fault Location to Capture (OFF, –1000.0–1000.0) OFF
MAXDIST Max Fault Location to Capture (OFF, –1000.0–1000.0) OFF
Table 5.57 Bay Settings (Sheet 1 of 2)
Label Prompt Default Value
MIMIC Busbar One-line Screen Number (1–999) 9
BAYNAME Bay Label b (max 20 characters) BAY 1
BAYLABx
a
Bay Label b (max 35 pixels, 5–9 characters) LABEL x
BUSNAMx Busbar b Name (max 40 pixels, 6–10 characters) BUSNAM x
ByHMINM
b
Breaker y HMI Name (max 17 pixels, 3–4 characters) BKy
BzCTLNM
c
Breaker z Cntl. Scr. Name (max 15 characters) Breaker z
