P.15.15
Date Code 20151029 Protection Manual SEL-411L Relay
ASCII Command Reference
Description of Commands
CPR
Use the CPR command to access the Signal Profile data for as many as 20
user selectable analog values. Notice that the CPR records are in reverse
chronological progression as compared to the PRO reports.
CSER
The CSER command is the SER command for the Compressed ASCII
command set. The default order of the CSER command (chronologically
newest to oldest from list top to list bottom) is the reverse of the SER
command (oldest to newest from list top to list bottom).
CSE
Use the CSE command to gather Sequential Events Recorder records. You can
sort these records in numerical or date order.
Ta b l e 1 5. 39 C P R C om m a n d
Command Description Access Level
CPR Displays the first 20 rows of the profile report,
with the oldest row at the bottom and the latest
row at the top.
1, B, P, A, O, 2
CPR m Displays the first m rows of the profile report, with
the oldest row at the bottom and the latest row at
the top.
1, B, P, A, O, 2
CPR m n (m > n) Displays the row between m and n, (including m
and n).
1, B, P, A, O, 2
CPR date1 Displays all the rows that were recorded on that
date, with the latest row at the bottom and the
oldest row at the top.
1, B, P, A, O, 2
CPR date1 date2 Displays all the rows that were recorded on and
between (including) date1 and date2 (date1
chronologically precedes date2), with the latest
row at the bottom and the oldest row at the top.
1, B, P, A, O, 2
CPR date2 date1 Displays all the rows that were recorded on and
between (including) date1 and date2 (date2
chronologically precedes date1), with the latest
row at the bottom and the oldest row at the top.
1, B, P, A, O, 2
CPR TERSE The CPR TERSE command omits the report
labels.
1, B, P, A, O, 2
Table 15.40 CSE Command (Sheet 1 of 2)
Command Description Access Level
CSE Return all records from the Sequential Events
Recorder in Compressed ASCII format, with the
most recent (lowest number) at the beginning of the
list and the oldest (highest number) at the end of the
list.
1, B, P, A, O, 2
CSE k
a
Return the k most recent records from the Sequential
Events Recorder in Compressed ASCII format, with
the most recent (lowest number) at the beginning of
the list and the oldest (highest number) at the end of
the list.
1, B, P, A, O, 2
CSE m n
b
Return the Sequential Events Recorder records in
Compressed ASCII format from m to n.
1, B, P, A, O, 2
If m is greater than n, then records appear with the
oldest (highest number) at the beginning of the list
and the most recent (lowest number) at the end of the
list.
