Sel 411L - Table 15.52 ETH C and ETH R Command; Table 15.53 EVE Command; Table 15.54 EVE a Command

P.15.20
SEL-411L Relay Protection Manual Date Code 20151029
ASCII Command Reference
Description of Commands
LINK SPEED DUPLEX MEDIA
PORT 5A Down --- --- TX
PORT 5B Down --- --- TX
PORT 5C Up 100M Full TX
PORT 5D Down --- --- TX
PACKETS BYTES ERRORS
SENT RCVD SENT RCVD SENT RCVD
0 8 0 512 0 4
Figure 15.1 Sample ETH Command Response
ETH C and ETH R
The ETH C and ETH R commands clear the Ethernet connection statistics.
Option C and R are identical.
When you issue the ETH C and ETH R command, the relay sends the
following prompt:
Are you sure (Y/N)?. If you answer Y <Enter>, the relay
clears the Ethernet statistics and response:
Ethernet Statistics Cleared.
EVENT
Use the EVENT command to view the relay filtered event reports (see Event
Report on page P.8.15 for information on event reports).
EVE
The EVE command displays the full-length event reports stored in relay
memory. When parameter n is 1–9999, n indicates the order of the event
report. The most recent event report is 1, the next most recent report is 2, and
so on. When parameter n is 10000–42767, n indicates the absolute serial
number of the event report.
EVE A
The EVE A command returns only the analog information in the event report.
Table 15.52 ETH C and ETH R Command
Command Description Access Level
ETH C Clears the statistics on Port 5 Ethernet connection 1, B, P, A, O, 2
ETH R Clears the statistics on Port 5 Ethernet connection 1, B, P, A, O, 2
Table 15.53 EVE Command
Command
a
a
Parameter n indicates event order or serial number.
Description Access Level
EVE Return the most recent event report (including
settings and summary) at full length with
4-samples/cycle data.
1, B, P, A, O, 2
EVE n Return a particular n event report (including
settings and summary) at full length with
4
-samples/cycle data.
1, B, P, A, O, 2
Ta b l e 1 5. 5 4 EV E A Co m m a nd
Command
a
a
Parameter n indicates event order or serial number; see EVE.
Description Access Level
EVE A Return only the analog information for the most
recent event report with 4
-samples/cycle data.
1, B, P, A, O, 2
EVE A n Return only the analog information for a particular
n event report with 4-samples/cycle data.
1, B, P, A, O, 2
