P.11.46
SEL-411L Relay Protection Manual Date Code 20151029
Testing and Troubleshooting
Factory Assistance
Factory Assistance
We appreciate your interest in SEL products and services. If you have any
questions or comments, please contact us at:
Schweitzer Engineering Laboratories, Inc.
2350 NE Hopkins Court
Pullman, WA 99163-5603 U.S.A.
Phone: +1.509.332.1890
Fax: +1.509.332.7990
Internet: www.selinc.com
Email: info@selinc.com
FPGA Failure
FPGA diagnostics failed during either
power up or run time.
In this rare event, the relay will automatically
restart. If the failure occurs three times in seven
days, the LCD displays the
FPGA FAIL screen.
Contact the SEL factory or your Technical Ser-
vice Center.
NOTE: Prior to firmware version R108, the relay
did not automatically restart. Contact the SEL
factory or your Technical Service Center.
Time/Date Errors
External IRIG time source error. Check IRIG-B time source or cables. Check
TIME Q command or
HMI SET/SHOW |
Date/Time
screen
1k PPS cable still connected. Remove 1k PPS cable.
IRIG-B connected to incorrect BNC
input.
Ensure that the correct BNC connector is being
used (see Figure 13.2).
A low-priority time source error. Check last update source (TIME Q command or
HMI SET/SHOW | Date/Time screen).
Lithium clock battery failure. Verify that the battery has failed before replacing
the battery—it should last for 10 years if the
relay is energized.
Table 11.15 Troubleshooting Procedures (Sheet 3 of 3)
Possible Cause Diagnosis/Solution
