P.2.44
SEL-411L Relay Protection Manual Date Code 20151029
Installation
AC/DC Connection Diagrams
cables in trenches, raceways, or wireways with unshielded power,
instrumentation, or control cables. Do not install twisted-pair cables in parallel
with power, instrumentation, or control wiring within panels, rather make
them perpendicular to the other wiring.
You must use a cable and connector rated as Category 5 (Cat 5) to operate the
twisted-pair interface (10/100BASE-T) at 100 Mbps. Because lower
categories are becoming rare and because you may upgrade a 10 Mbps
network to 100 Mbps, we recommend using all Cat 5 or better components.
Some industrial Ethernet network devices use 9-pin connectors for STP
cables. The Ethernet card RJ45 connectors are grounded so you can ground
the shielded cable using a standard, externally shielded jack with cables
terminating at the Ethernet card.
AC/DC Connection Diagrams
You can apply the relay in many power system protection schemes.
Figure 2.42 shows one particular application scheme with connections that
represent typical interfaces to the relay for a single circuit breaker connection.
Figure 2.43 depicts typical connections for a dual circuit breaker protection
scheme.
