Front-Panel Menus and Screens
event in the display, exit the SER screen by pressing ESC and re-enter the SER
Events
screen by pressing ENT with the SER Events selection highlighted.
This rebuilds the
SER Events display and contains the latest SER events
triggered.
NOTE: Display either 3 or 5 SER
events per screen to display, set front-
panel setting SER_PP = 3, to display 5,
set SER_PP = 5.
Figure 7.23 SER Events Screen With Three Events
If no SER events are available, Figure 7.24 is displayed.
Figure 7.24 No SER Events Screen
While viewing the SER events, front-panel pushbuttons provide navigation
and control functions as indicated in Tabl e 7.7.
Hold down either the Up Arrow or Down Arrow to achieve accelerated scrolling.
Holding down the Up Arrow or Down Arrow navigates one screen at a time for
the first five screens, and then increases to five screens at a time if the button
remains pressed. Accelerated scrolling stops at the newest or oldest SER event
record available, depending on the direction of the scrolling.
When the upper limit of the SER events is reached, press the Down Arrow one
more time and the report will wrap around to display the screen containing the
first SER event. Similarly, when the lower limit of the SER events is reached,
press the Up Arrow one more time and the report will wrap around to display
the screen containing the last SER event.
Table 7.7 Front-Panel Pushbutton Functions While Viewing SER Events
Pushbutton Description
Up Arrow,
Down Arrow
Navigates one screen at a time up or down. Each screen contains
three SER events. Accelerated scrolling is obtained when the push-
button remains pressed (see accelerated scrolling behavior below).
Left Arrow,
Right Arrow
Navigates between SER events to allow adjacent SER events to be
displayed on one screen. For example, if events 1, 2, and 3 are dis-
played, press the Right Arrow once to display events 2, 3, and 4 in the
same screen. No accelerated scrolling is provided with the Left Arrow
and Right Arrow pushbuttons.
ESC Returns to the Events Menu
ENT Does nothing
Local
Disabled
02/16/06 11:11:01.993
Local
Enabled
02/16/06 10:11:19.090
IN201
Asserted
02/16/06 03:22:01.988
SER Events 001-003
No SER Events
Available
