Sel 411L - Manual; Table A.5 Manual Revision History

P.A.9
Date Code 20151029 Protection Manual SEL-411L Relay
Firmware and Manual Versions
Manual
Manual
The date code at the bottom of each page of this manual reflects the creation
or revision date.
Table A.5 lists the instruction manual release dates and a description of
modifications. The most recent manual revisions are listed at the top.
ICD-411L-R102-V0-Z111005-D20131021 Enabled selectable GOOSE Filtering, Embedded
relay settings files, 128 GOOSE subscriptions,
256 VBs, GOOSE Min TX time, 7 MMS reports/
sessions, MMS Authentication, Support for third
I/O board, Extension to Z-Based RFLO, New
RFLO for Traveling Wave
R111 005 20131021
ICD-411L-R102-V0-Z000000-D20130619
b
SEL-411L ICD file for firmware R109 or higher. R109 004 20130401
ICD-411L-R101-V0-Z000000-D20110928
b
SEL-411L ICD file for firmware R103 or higher. R103 004 20120228
ICD-411L-R100-V0-Z000000-D20110422
b
SEL-411L ICD file for firmware R100 or higher. R100 004 20110518
configVersion Details:
ICD-[PN]-R[RN]-V[VS]-Z[FC]-D[RD] where:
[PN] = Product Name (e.g. 421)
[RN]
c
= Revision Number (e.g. 102)
[VS] = Version Specifications (e.g. 9)
[FC]
d
= Minimum Relay Firmware and Class File Version (e.g. 311005)
[RD] = Release Date Code (e.g. 20150219)
a
The configVersion can be determined for the IED by performing an ID ASCII command from a terminal connection.
b
The minimum relay firmware and ClassFileVersion in this configVersion does not have a meaningful value.
c
This is the ICD file revision number, not IED firmware revision number.
d
FC consists of six digits. The first three following the Z represent the minimum IED firmware required to be used with the ICD (e.g. 516). The
second three represent the ICD ClassFileVersion (e.g. 005).
Table A.4 SEL-411L ICD File Revision History
configVersion
a
Summary of Revisions
Minimum
Relay
Firmware
ClassFile
Version
Manual
Date Code
Table A.5 Manual Revision History (Sheet 1 of 6)
Revision Date Summary of Revisions
20151029
Protection Manual
Appendix A
➤ Updated for firmware version R117-V2
➤ Updated text to describe point release.
20150716
Protection Manual
Appendix A
➤ Updated for firmware version R117-V1.
➤ Updated text to describe point release.
20150626
Protection Manual
Section 1
➤ Updated Specifications.
